Glassfiber High Temperature HEPA Filter With SS Frame And Alluminum Separators

350℃ H13 High-Temperature Glassfiber HEPA Filter With Stainless Steel Frame And Alluminum Separators

350℃ Heat Resistant Absolute 1FRK^® Series Hepa Air Filter Stainless Steel Frame

HEPA H13 filter for VERY high temperature applications (e.g. sterilization tunnels) up to 350℃ as protection for clean processes.

Stainless steel frame and aluminum separators give high stability.

Pleates are uniformly separated by corrugated aluminum separators incorporating a hemmed edge to prevent damage to the media.

• High temperature HEPA Filter
• Filter class H13 acc. to EN 1822 (at 20℃)
• High air velocity (1,5m/s)
• Maximum continuous operating temprature 350℃
• 100% leak-free: individually scan tested at 20℃
• High mechanical stability

Tolerance of pressure drop ±15%

Other dimensions & gasket on request

Type -1W= gasket upstream (standard)

Please note installation and assembly instructions! Due to the different thermal expansion coeffiecients of the individual filter components the ceramic potting may form cracks during the tempering process. At operating temperature (350℃) these filters have an overall efficiency of 99.97% at 0.3μm, leackages are possible.
