9V Battery Operated Personal Lpg Gas Leak Detector Alarm, Shut-off Valve Optional

                    AC110-230V Personal Lpg Gas Leak Detector Alarm with Solenoid/Shut-off Valve

HD1100 with display is a new standalone AC powered Personal Lpg Gas Leak Detector Alarm, protecting your family from the dangers of explosive gas such as LPG. It adopts highly accurate catalytic gas sensor and utilizes sophisticated electronic components, offering a high level of functionality, reliability and flexibility.

HD1100 is complete with a special circuit that control the catalytic sensor’s efficiency level, and signals any possible fault and it has power, pre-heat, fault and alarm indications, as well as a control button for test(press) and rest (press and hold for more than 5 seconds).

Application:

HD1100 Personal Lpg Gas Leak Detector Alarm is optimized for use by professionals with coal gas leak detection and it is ideally suited for use in private or social housing, such as bedrooms, hotels, hospitals and even dormitory rooms where the coal gas pose a substantial hazard if a leak occurs.

Features & Benefits:
Detecting gas natural/methane gas and propane gas, coal gas etc combustible gas.

HD1100A For Natural Gas

HD1100C For carbon monoxide
HD1100D For 2 gases in one, for double gases together is optional.
High reliability-- Catalytic combustion gas sensor
                    -- Professional low profile design
                    -- With special circuit(MCU processing control and SMT manufacture Technology).
                    -- Comply to GB15322.2-2003.
Easy to Install --Unit plugs directly into any wall outlet.
Easy operation --Clearly visible status indications LEDS (power, preheat, fault and alarm).
                      -- Button for test and rest: Test the alarm electronics and reset the unit during alarm.
                      --Loud 80dB at 1m
Low total cost --Ideal for easy installation
                     --Direct connection to a solenoid valve
                     --5 years working life with 2 year guarantee.
Designed for residential environments—Slim,small, compact design with stylish features, ideal for residential setting and modern decorations.

Model: HD1100A

Detecting principle: catalytics combustion sensor
Alarm level:  7%LEL
Accuracy: +/-3%
Audible alarm level: 80dB at 1m

Wireless Singnal: GPRS, ZIGBEE (contact us if special requires)

Power supply: 110V-230VAC 50/60Hz, 9V Backup Battery
Temperature: -10℃~+55℃
Output: Gas shut off valve output or relay output
Humidity: ≤95%RH (no condensation)
Net Weight: 330g
Wiring: plug-in
Size: 118mm (L)×78mm(W) ×38mm(H)
Lifetime/Warranty: 5years/ 2 years.

Detailed Images

Company Information

Established in 2004, Henan Chicheng Electronics Co.,Ltd is speclized in the R&D, manufacture, marketing of gas detector device in China, we can always supply you professional technical support and solutions.

With ISO9001-2000 Certified, Chicheng products are mainly divided into household gas alarm, portable single/multi gas detector, industrial fixed gas detecting transmitter, etc.

Henan Chicheng has a mission to offer proper device and excellent all-round services to customers from automotive production plants, petrochemical, gas, pharmaceutical and metallurgical industries.

Sincerely welcome customers worldwide. OEM and ODM welcome!
