1500RPM 50HZ Heavy Range Triphase AP2250 Perkins Generator 4016TAG2A PRP 2000 LTP 2250
Perkins 1500RPM 50HZ Heavy Range Triphase 400/230V Model AP2250 Perkins 4016TAG2A PRP 2000 LTP 2250
AI power UK series generator set adopts UK engine as the power source. It’s one of the world’s leading diesel engine manufacturers since 1932, produced nearly 400,000 units for one year and quickly occupied the world market for the full specification, good structure, reliable performance, easy maintenance, low exhaust and long period maintenance. Perkins service network is in more than 180 countries and regions.
Specifications:
| Technical Data | |||||
| GENSET | Manufacturer | AI POWER | |||
| Model | AP2250 | ||||
| Frequency | 50HZ | ||||
| Power | Standby Power | 1760KW 2200KVA | |||
| Prime Power | 1600KW 2000KVA | ||||
| Open type | Dimension(L*W*H) | Open-mm | 5700×2800×2900 | ||
| Dimension(L*W*H) | canopy-mm | 40HQ | |||
| DIESEL ENGINE | Engine Manufacturer | Perkins | |||
| Model | 4016TAG2A | ||||
| Cylinder Arrangement | 16 | ||||
| Cycle | 4 stroke | ||||
| Aspiration | Turbocharged air-air cooled | ||||
| Bore×Stroke (mm×mm) | 160 x 190 | ||||
| Displacement(Liter) | 61.123 | ||||
| Compression Ratio | 13.6:1 | ||||
| Prime Power/Speed (kW/rpm) | 1715/1500 | ||||
| Standby Power/Speed (kW/rpm) | 1886/1500 | ||||
| Speed Governor | Electrical | ||||
| Cooling System | Water-cooled | ||||
| Total lubrication system capacity (L) | 237.2 | ||||
| Coolant capacity (inc. radiator) (L) | 95 | ||||
| Fuel Consumption at 100% Load (g/kWh) | 209(at 1500RPM) | ||||
| Alternator | Manufacturer | Stamford | |||
| Model | PI734F | ||||
| Rated Voltage | 230/400V | ||||
| Voltage regulation mode | Auto | ||||
| Exciter Type | Brushless self exciting | ||||
| Power factor | 0.8 | ||||
| Capacity (Kva) | 2080 | ||||
| Insulation class | H | ||||
| Protection class | IP23 | ||||
Product Details
Features
Economic power
- Individual 4 valve cylinder heads giving optimised gas flows
- Unit fuel injectors ensure ultra fine fuel atomisation and hence controlled rapid combustion
- Commonality of components with other engines in the 4000 Series family for reduced stocking levels
Reliable power
- Developed and tested using the latest engineering techniques
- Piston temperatures controlled by an advanced gallery jet cooling system
- Tolerant of a wide range of temperature without derate
Compact, clean and efficient power
- Exceptional power to weight ratio and compact size give optimum power density for easier transportation and
installation
- Designed to provide excellent service access for ease of maintenance
- Engines to comply with major international standards
- Low gaseous emissions that will satisfy the requirements of ½ TA Luft (1986)
Product support
- Perkins actively pursues product support excellence by ensuring our distribution network invest in their territory – strengthening relationships and providing more value to you, our customer
- Through an experienced global network of distributors and dealers, fully trained engine experts deliver total service support around the clock, 365 days a year. They have a comprehensive suite of web based tools at their disposal covering technical information, parts identification and ordering systems, all dedicated to maximising the productivity of your engine
- Throughout the entire life of a Perkins engine, we provide access to genuine OE specification parts and service. We give 100% reassurance that you receive the very best in terms of quality for lowest possible cost .. wherever your Perkins powered machine is operating in the world
1. What is your warranty period?
A: It’s 1 year or 1000 running hours whichever comes first. But based on some special project, we can extend our warranty period.
2. Can you accept OEM?
A. Yes, we can accept OEM.
3. What’s your payment term?
A: We can accept T/T 30% in advance and the balance 70% shall be paid before shipment or LC at sight.
4. What’s your delivery time?
A: Our normal delivery time is 2 to 4 weeks. But if your order is some special engine and alternator, the delivery time will be longer.
