Industrial Low Rpm Permanent Magnet Alternator Brushless Generator 12 KW 16KW 20KW 30KW 40KW 50 kva 100kva
Industrial Use 12 KW 16KW 20KW 30KW 40KW 50 kva 100kva Low Rpm Perman Magnet Alternator Brushless Generator
A Brushless alternator is made up of two alternators that are built end-to-end on a single shaft. Smaller brushless alternators may appear to be a single unit, but the two parts are easily distinguishable on larger models. The main alternator is the larger of the two sections, and the exciter is the smaller. The exciter contains stationary field coils as well as a rotating armature (power coils). The primary alternator employs the inverse configuration, with a rotating field and a stationary armature.
Leroysomer 100KW Alternator Specification:
| Alternator manufacturer | Leroy-somer Electro-technique (Fuzhou) Company Ltd. | |||||||||||
| Alternator brand | Leroysomer | |||||||||||
| Alternator model | TAL-A44-E | |||||||||||
| Control system | SHUNT | |||||||||||
| A.V.R. | Included | |||||||||||
| Voltage regulation | ±1.0% | |||||||||||
| Insulation system | Class H | |||||||||||
| Protection | IP23 | |||||||||||
| Rated power factor | 0.8 | |||||||||||
| Winding pitch | Two thirds | |||||||||||
| Winding leads | 6 | |||||||||||
| Frequency (Hz) | 50 | |||||||||||
| Voltage (V) | 400 | |||||||||||
| Phase | 3 | |||||||||||
| Output ratings (kVA/kW) | ||||||||||||
| ----------------Cont.H-40°C | 125/100 | |||||||||||
| ----------------Standby-27°C | 137.5/110 | |||||||||||
| THF | <2% | |||||||||||
| TIF | <50 | |||||||||||
| Max. overspeed (Rev/Min) | 2250 | |||||||||||
| Bearing | Single | |||||||||||
IP23 Brushless PMG Alternator Products
AI POWER is the professional manufacturer of power generator in China. We provides a complete line of generators for commercial,industrial and residential application.We specialize in providing a wide range of well known and trusted brands of diesel generators, supplying generators from 5kw to 2000kw at competitive prices.
