Kubota 15kw 415V Water Cooled Portable Diesel Generator V2203
Super Silent Japanese Brand Water Cooled 15kw Kubota Portable Diesel Generators
Kubota Engine
The Kubota V2203 is a vertical, water-cooled, 4-cycle diesel engine with a capacity of 39.9HP at 2800RPM. Featuring a built-in solenoid, low fan position and single side serviceabilty, the Kubota V2203 offers powerful performance, exceptional reliabilty and a long service life to meet almost any application.
- Kubota was the first manufacturer to receive the certificate for the U.S. CARB ULGE emission regulations for engines under 19 kw in 1993.
- Every engine shipped from the Kubota factory is hot tested to ensure the engine performs to your expectations.
- Kubota manufacturing technology enables precision engineered crankcases to maintain high quality throughout production.
Engine Specifications:
|
|
V2203 |
|---|---|
|
Type |
Water Cooled Vertical Diesel Engine |
|
Number of Cylinder |
4 |
|
Bore & Stroke |
80.0mm x 92.4mm |
|
Total Displacement (cc) |
2197 |
|
Combustion System |
E-TVCS |
|
Intake System |
Naturally Aspirated |
|
Max Output Net Intermittent kW/rpm (hp/rpm) |
34.3/2800 (46.0/2800) |
|
Maximum Output Continuous kW/rpm (hp/rpm) |
29.8/2800 (39.9/2800) |
|
Continuous Output Generator Spec kW/rpm(hp/rpm) |
17.1/1500 (32.0/1500) |
|
Starting System |
Electric Start |
|
Housing Options |
SAE #4 - 7 1/2" Housing/Flywheel or Standard Kubota Flywheel /Housing |
|
Options |
Full Power Pack Options |
|
Alternator manufacturer |
Xiamen Ai Power Technology Co., Ltd. |
|||||||||||
|
Alternator brand |
AI POWER |
|||||||||||
|
Alternator model |
AI184E |
|||||||||||
|
Control system |
SELF EXCITED |
|||||||||||
|
A.V.R. |
Included |
|||||||||||
|
Voltage regulation |
±1.0% |
|||||||||||
|
Insulation system |
Class H |
|||||||||||
|
Protection |
IP23 |
|||||||||||
|
Rated power factor |
0.8 |
|||||||||||
|
Winding pitch |
Two thirds |
|||||||||||
|
Winding leads |
12 |
|||||||||||
|
Frequency (Hz) |
50 |
|||||||||||
|
Voltage (V) |
400 |
|||||||||||
|
Phase |
3 |
|||||||||||
|
Output ratings (kVA/kW) |
|
|||||||||||
|
----------------Cont.H-40°C |
20/16 |
|||||||||||
|
----------------Standby-27°C |
22.5/18 |
|||||||||||
|
THF |
<5% |
|||||||||||
|
TIF |
<50 |
|||||||||||
|
Max. overspeed (Rev/Min) |
2250 |
|||||||||||
|
Bearing |
Single |
|||||||||||
Features
-
Kubota’s E-TVCS indirect injection system provides high power output and torque backup in a compact package.
-
Half-float valve cover and coated pistons offer lower noise levels than conventional diesel engines and provide reduced transmitted vibrations from the valve area for better noise characteristics.
-
Kubota’s original casting technology protects the engine against heat load of high power density, providing superior endurance and reliabilty.
-
Renowned for its exceptional reliability and long service life.
-
Super glow system for shortening pre-heat time and quicker engine start-up in cold weather.
Factory Overviews
FAQ
1.Are you a factory or trading company?
2.What is the material of your products?
A: Iron, Steel, plastic, etc.
3.How about quality control in your factory?
A: AI people are always paying great attentions to quality controlling from the beginning to the end.
4.How about your guarantee?
A: Our warranty period is 1 year or 1000 running hours, whichever comes first.
