360kw 450kva Volvo Penta Diesel Generator TAD1345GE Diesel Electric Generator
Original Sweden Volvo Generator Set TAD1345GE 360kw 450kva Generator Power Range
Original: VOLVO PENTA – VOLVO GROUP
Made in: Sweden
– Model: TAD1345GE-B
– Prime: 388kW
– Stanby: 431kW
– 4 Stroke diesel engine with direct injection
– Turbocharged
(Number of cylinders)
– 6 cylinders
– Displacement: 12,78 liter
– Bore: 131 mm
– Stroke: 158 mm
– Firing order: 1-5-3-6-2-4
– Compression ratio : 18,1:1
(Starter system)
– Electric started
– Alternator:
+ Made by: Bosch
+ Output : 80A
+ Automatic pressure regulator
– Starter motor:
+ Made by : Melco
+ Type: 105P70
+ Power: 7 kW
+ Voltage: 24V
(Shutdown system)
– Electric shutdowned
– 24VDC coil to stop motor
Engine SPECIFICATIONS
| Continuous Power | 451 kVA |
| Standby Power | 501 kVA |
| Cylinders | 6 |
| Cubic Capacity | 12,78 l |
| Air Intake | Turbocharged |
| Cooling | Water |
| Fly Wheel | 388 kW |
FUEL CONSUMPTION
| Consumption @ 110% | 100,6 l/h |
| Consumption @ 100% | 90,5 l/h |
| Consumption @ 75% | 68,2 l/h |
| Consumption @ 50% | 46 l/h |
| Consumption @ 25% | 25,1 l/h |
PERFORMANCE
| BMEP | 2500 kPa |
|
| Speed | 1500 rpm |
|
| SAE | 1-14 |
|
| TA Luft | Not available |
|
| TA Luft 2 | Not available |
|
| EPA | Not available |
|
| Stage | STAGE II |
|
| Elec. Regulator | Standard |
|
| Precision Class | G3 |
|
| Weight | 1325 kg |
|
LIQUIDS & HEAT
| Oil Quantity | 36 l |
| Antifreeze Quantity | 24 l |
| Antifreeze Radiator | |
| Total Antifreeze | 24 l |
| Heat to Radiator | 145 kW |
| Heat to Exhaust | 268 kW |
| Heat to Radiation | 15 kW |
| Exhuast Temprature | 475 °C |
| Cooling Airflow | N/A |
| Combustion Airflow | 26,8 m³/min |
| Exhuast Gas Flow | N/A |
