Uniboot LC Fiber Optic Patch Cord For Networking Cabling
Introduction of Uniboot LC Fiber Optic Patch Cord
Uni-boot LC is a duplex LC connector with a single boot, dubbed the LC Uni-boot. The connector's design allows asingle round duplex 3 mm cable to be used for a duplex connector. The single piece design fits all duplex adapters. By using a single cable with two fibers, installers are able to cut their cable count and weight in half. The design is suitablefor use in data centers where cable counts are high and space is limited.
Uni-boot optical fiber patch-cord is ideal for interconnection of SAN switches, networking equipment and fiberchannel devices that require up to 10Gbps data transmission.
Features and Benefits of Uniboot LC Fiber Optic Patch Cord
1) High-quality ferrules.
2) Bend-insensitive/bend optimized fibers.
3) Low loss or standard loss connectivity.
4) Compact, single cable with two fibers.
5) Plastic housing and boot made from UL-rated materials.
6) Fully compatible with standard LC products.
7) Uni-boot LC switchable function meet the flexible connection.
8) Pulling tab for easy access to connectors in high density environments.
Technical Data of Uniboot LC Fiber Optic Patch Cord
| Mechnical Data | Value |
| Connector Type | Push pull or no push pull |
| Polarity Type | Fixed or Switchable |
| Cable Diameter | 2.0mm or 3.0mm round |
| Cable Jacket Color | Yellow, Orange, Aqua, Violet, Green |
| Optical Data | Value |
| Fiber Mode | OS1/OS2 - 9/125 bend insensitive or 1/2/3/4/5 |
| Fully Compliant | 850nm (Multimode), 1310nm/1550nm (Singlemode) |
|
IL(Low Loss) |
Singlemode≤0.10dB, Multimode≤0.10dB |
| IL(Standard Loss) | Singlemode≤0.3dB, Multimode≤0.3dB |
| Return Loss |
Singlemode UPC≥50dB APC≥60dB Muiltmode UPC≥25dB |
Environment Data
| Description | Value |
| Operating Temperature | -20℃ to +60℃ |
| Store Temperature | -20℃ to +60℃ |
| Fully Compliant | IEC-61754, TIA/EIA-604, GR326, RoHS |
Odering Information
| - | x | x | x | x | x | x | x |
| Type | Polish | Fiber Mode | Insertion Loss | Polarity | Push Pull | Jacket | Length |
| UBLC |
1=UPC 2=APC |
1=OS1 2=OS2 3=OM1 4=OM2 5=OM3 6=OM4 7=OM5
|
1=Low Loss 2=Standard Loss |
1=A-A 2=A-B |
1=Yes 2=No |
1=LSZH 2=PVC |
01=01m
...
99=99m |
Note: APC only OS2 fiber mode.
Example:
UBLC 111122103
Means : Uni-boot LC, LC/UPC - LC/UPC, OS2, Low Loss, Polarity A-A,No push-pull, OD 3.0mm, LSZH, 3M Length.
Our certificates
1) ISO9002
2) SGS, ROHS
3) ULE329066
4) REACH
Testing Lab
| No | Device name | No | Device name |
| 1 | Optical time domain reflectometer (OTDR) | 8 | GNZV Cable Torsion Testing Machine |
| 2 | Fiber Polarization Mode Dispersion | 9 | GQNV Cable Flexing Testing Machine |
| 3 | Fiber Dispersion ,Strain Tester | 10 | GJRV Cable Winding Testing Machine |
| 4 | High Low Temperature Test Chamber | 11 | GZDV Cable Vibration Testing Machine |
| 5 | Cable Impact Testing Machine | 12 | Cable Water Penetration Test |
| 6 | Cable Squash Tensile Testing Machine | 13 | Fusion Splicer |
| 7 | GWQV Cable Bending Tester | 14 | Cable Water Penetration Test Rig |
Advantages of our Uniboot LC Fiber Optic Patch Cord
1) Professional cable manufacturer
2) About 20 years experiences in cable industry
3) MOQ just 1Km
4) ISO, UL , ROSH,REACH...certifications
5) Can be customized production of fiber optic cable
Images of Uniboot LC Fiber Optic Patch Cord and part of certifications
