Acid Resistance PVC Window Screen Wire Mesh 100 feet length Vinyl Coated Fiberglass

                                                    Vinyl coated fiberglass insect screening

Vinyl coated fiberglass insect screening, also called vinyl coated glass yarn insect screening, refers to the fibrous glass yarn with vinyl chloride resin coating. It is a type of popular window screen material in all over the world. Vinyl coated fiberglass insect screen has excellent flame resistance and UV resistance performance. Additional, it is corrosion, acid and alkali resistance to ensure the long service life. Vinyl coated fiberglass insect screen has simple but strong structure, which will not loose when it is cut into pieces. It is convenient to install and replace and it is very easy to clean.

Vinyl coated glass yarn insect screening is produced in two basic classes and mesh to afford required strength and insect protection using yarn.

• Class 1: fly screening woven from vinyl coated glass having a nominal thickness of 0.292 mm (0.0115 inch).
• Class 2: insect screening woven from vinyl coated glass yarn having a nominal thickness of 0.330 mm (0.013 inch).

Specifications of vinyl coated glass yarn insect screening

• Material: vinyl coated fibrous glass yarn.
• Workmanship: plain weave.
• Wire diameter: standard is 0.292 mm and 0.330 mm.
• Mesh size: standard is 18 mesh × 16 mesh, other mesh sizes refer to the Table 1.
• Weight: standard is 120 g/m2. It can also be 85 g/m2, 90 g/m2, 100 g/m2, 110 g/m2, 115 g/m2, 130 g/m2, 140 g/m2, 145 g/m2.
• Available width: 610 mm, 762 mm, 813 mm, 914 mm, 1067 mm, 1219 mm, 1524 mm, 1829 mm, 2134 mm, 2438 mm, 2743 mm, etc.
• Available length: 25 m, 30 m, 45 m, 50 m, 180 m.
• Available color: standard is gray and charcoal. It can also be white, black, blue, green and other customized colors based on RAL.
