OEM 98% AZ61 Magnesium Alloy Rod Dia 100MM Magnesium Bars
OEM Supplier AZ61 Extruded And Casting Magnesium Alloy Rod 10-100MM
Product Description
We ave advanced die-casting, extrusion, forging, rolling, casting processing production line and precision testing equipment and can produce a variety of types of magnesium alloy and magnesium alloy products, and developed a high-strength magnesium alloy extruded sheet. Through the purification of ordinary magnesium, magnesium can be raised up to 99.99% of high purity.
A series of technical problems such as grain refinement and composition segregation control of large-size semi-continuous cast rods have been overcome, and the product quality has been improved, and the production cost of the subsequent extrusion of the enterprise has been reduced. The magnesium alloy blanks of specific grades can be produced according to customer needs.
Main market: US, Canada, Korea, Japan, Turkey, Germany, UK, Sweden etc.
Product Name
Magnesium Alloy Rod
Hot Rolled Magnesium Alloy Rod
Cold Rolled Magnesium Alloy Rod
Large Diameter High Strength Rare Earth Magnesium Alloy Rod
High Performance Magnesium Alloy Rod
Specification & Chemical Composition
| Item | Magnesium Alloy Rod AZ61 | ||||
| Material | Magnesium Rod | ||||
| Thickness | as customer's required | ||||
| Width | as customer's required | ||||
| Length | as customer's required | ||||
| Size | customize | ||||
| Features of Magnesium Alloy Rod | 1.fast heat dissipation,light and good rigidity | ||||
| 2.Good corrosion resistance and dimensional stability | |||||
| 3.Good impact resistance and wear resistance | |||||
| 4.Good absorption of vibration energy performance | |||||
| 5.high thermal and conductive properties | |||||
| 6.non magnetic, good shielding and non-toxic characteristics | |||||
Specification & Chemical Composition
Diameter: 30- 800mm
Length is required of customer
Product specification are tailored to customer's requirements
Features of Megnesium Alloy
- Good ductility and corrosion resistance,
- High electrical and thermal conductivity,
- Good room temperature strength at room temperature
- Suitable for round, flat and square bars, pipes, plates and forgings
Size of magnesium alloy sheet plate/sheet
Type: AZ31B, ZK61M, AZ80A, AZ91D, M2M, ME20M, AZ40
Specification: Casting round bar billet(Φ3-160*3000)
Remarks: According to the requirements of sawing and heat treatment
Physical Property:
Density: 1.8
Coefficient of thermal expansion: 26.8 x 10-6K-1
Specific heat: 1040 Jkg-1k-1
Thermal conductivity: 76.9Wm-1k-1
Electrical resistivity: 92nΩm
Modulus of elasticity: 45 x 109Pa
Poissons ratio: 0.35
Melting range: 566 - 632°C.
Chemical Composition:
| Grade | Chemical Composition, % | ||||||||
| Al | Zn | Mn | Zr | Si | Fe | Cu | Ni | Mg | |
| AZ31 | 2.4-3.6 | 0.15-1.5 | 0.15-0.40 | ≤0.10 | ≤0.05 | ≤0.05 | ≤0.005 | Balance | |
| AZ40 | 3.0-4.0 | 0.20-0.80 | 0.15-0.50 | ≤0.10 | ≤0.05 | ≤0.05 | ≤0.005 | Balance | |
| AZ61 | Balance | ||||||||
| AZ80 | 5.5-6.5 | 0.5-1.5 | 0.15-0.40 | ≤0.10 | ≤0.005 | ≤0.05 | ≤0.005 | Balance | |
| AZ91 | 8.5-9.5 | 0.45-0.90 | 0.07-0.40 | ≤0.08 | ≤0.004 | ≤0.025 | ≤0.001 | Balance | |
| ZK61 | ≤0.05 | 5.0-6.0 | ≤0.1 | 0.45-0.80 | ≤0.05 | 0.05 | ≤0.05 | ≤0.005 | Balance |
| M1A | 1.2-2.0 | 0.1 | 0.05 | 0.01 | Balance | ||||
Application
Carving, aerospace, concrete tools, 3C (cell phone / camera / computer), water heater, refrigerator, gas pipelines etc.
Advantage of our Company:
Full range of product types, Ensure production capacity
We ave advanced die-casting, extrusion, forging, rolling, casting processing production line and precision testing equipment and can produce a variety of types of magnesium alloy and magnesium alloy products, and developed a high-strength magnesium alloy extruded sheet. Through the purification of ordinary magnesium, magnesium can be raised up to 99.99% of high purity.
Our Services
1. Small order quantity available
2. Professional engineering team and sales team
3. Payment: 100% by T/T in advance & Western Union
4. OEM/ODM available
5. Free samples provided
6. Competitive price and high quality
Certificate
We have attained ISO9001 and SGS certificate, standardize and improve the enterprise quality management system
FAQ
1. Q: Are you a factory or trading company?
A: We are direct manufacturer located in Zhengzhou Henan province, and have our equipment as well as plant
2. Q: Are your products customized?
A: Yes, the products in the website are only the common type or the previous types, we can supply the new products according to your requirements or drawings
3. I do not know how to use your product ?
Do not worry ! We can supply technical guidance together with products
4. Q: How can I get some samples?
A: Several samples are freely offered for buidling the business long-term relationships and letting our customers believing the quality of our products
5. Q: How does your factory do regarding quality control?
A: We passed ISO 9001 and SGS certificate
