Tumblin Precision CNC Parts Automatic Lathe 0.05mm Tolerance
Rapid Prototyping Precision CNC Parts Precision Machined Products Custom Cnc Parts
Product Description
We XinBo Precision has been engaged producing and supplying all kinds of CNC Milling parts over 10 years. Our flagship products include Brackets, Covers, Housings, etc. Conforming to all customer’s prints and the tolerance standard: ISO2768m, ISO2768f. These product supports a variety of applications, including chemical equipment, automotive industry, consumer electronics, etc.
Except CNC machining, we also provide one stop solutions like heat treatment, finishing, assembly and inspection.
Our reputation for precision craftsmanship, a diverse work environment, and fast turnaround times means you can count on getting the exact parts you need, exactly when you need them. It’s an advantage your business will be able to measure on the bottom line. Helping our customers optimize the simple, simplify the difficult, and realize the impossible.
| Name | Custom Manufacturing Service, CNC Turning Parts. |
| Materials |
6061-T651 AMS 4117, 7049-T7351 AMS4200, 7050-T7451 AMS4050, 7075-T7351 AMS4124 |
| Surface Treatment |
E-Coating, Chemical Conversion, Laser Marking, Laser Engraving, Laser Etching |
| Tolerance | ISO2768m, ISO2768f, 0.005mm. |
| Testing equipment | CMM; Tool Microscope; Automatic Height Gauge; Manual Height gauge; Dial Gauge; Screw Gauge; Plug Gauge; Micrometer; Marble Platform; Roughness Measurement |
| Processing | CNC milling, CNC machining, Grinding, EDM Wire Cutting, Sink EDM, Turning |
| File Formats | Solid Works, Pro/Engineer, AutoCAD(DXF,DWG), IGS,STP, PDF,TIF etc. |
| Service Project | Free Design Review(DFM report), Production And Technical Service. |
| Roughness | Ra0.4, Ra0.8, Ra1.6,Ra3.2, As machined. |
Machining Equipment
| Name | Module | Range | Brand | Origin | Qty. | Precision |
| CNC Milling | VMC850/VMC1270 | V500-1270mm | Baoming/Baojia/Weikun | China | 26 | 0.02mm |
| CNC Milling | 4 axis | 200mm | BangBang | China | 5 | 0.005mm |
| CNC Milling | 5 axis | 200mm | BangBang | China | 1 | 0.005mm |
| CNC Milling | S500X1 | 500*400*300 | Brother | Japan | 2 | 0.005mm |
| Automatic Lathe | MC7036B/MC7020XE | 1-100mm | ZhongTai | China | 8 | 0.01mm |
| CNC Lathe | VT-17L | 215*470mm | Alex-Tech | Taiwan | 1 | 0.002mm |
| Turn-mill Combination | B0203-III | 1-46mm | TSGAMI | Japan | 4 | 0.002mm |
| Surface Grinder | PSGC-4080 AHR | 400*800mm | Proth | Taiwan | 2 | 0.002mm |
| Grinder | 520 | 200*400mm | Taizheng | China | 6 | 0.005mm |
| Mill Machine | 3# | 200*1000mm | Jietongda | China | 8 | 0.02mm |
| High Speed Wire Cut | 200*500mm | Jicheng | China | 4 | 0.02mm | |
| Medium Speed Wire Cut | DK7732C-C | 320*400mm | Baoma | China | 4 | 0.01mm |
| Laser Engrave Machine | G20 | Cherrywoolf | China | 1 | ||
| Other equipment:Drill machine, Tapper, Polisher, EDM puncher, Ultrasonic cleaner, Sand blaster machine, Saw machine, Magnetic grinder. | ||||||
Inspection Equipment
| Name | Module | Measuring range | Brand | Origin | Qty. | Precision |
| Height gauge | Hite-400 | 0-400mm | TESA | Swiss | 4 | 0.003um |
| Projector | VMS-3020 | 0-400mm | Video | Japan | 2 | 0.003um |
| CMM | CROMA 564 | 500*600*400mm | SERERN | Joint venture | 2 | 0.003um |
| Hardness tester | HR-150C | 20-88HRA,20-100HRB,20-70HRC | Rockwell | China | 2 | 0.5HRC |
| Film thickness gauge | AR932 | 0-1700um | Smartsensor | China | 2 | |
FAQ
When do not make parts by 3D printing?
- Mass production. When you have hundreds or thousands parts to make, the parts can be made by CNC machining, die casting, sand casting, forging, or powder metallurgy, the unit price could be much lower.
- Smooth finish. The CNC turning can get at least Ra0.8 μm roughness, CNC milling can get at least Ra0.8 μm roughness. Currently the 3D printing parts can’t have as fine surface as CNC machining.
- Special material. For CNC machining, you can have different grade material from different material supplier, for example you can select AISI 316L stainless steel for CNC machining, but for 3D printing, you can only have “stainless steel” for option, the material property will have slightly difference.
- Heat treatment. So far the 3D printing metal parts have brittle surface, the machined parts can do heat treatment, so the machined parts could have better mechanical property.
- Tight tolerance. CNC machining can meet very tight tolerance(as tight as μm grade), 3D printing can’t as precise as CNC machining.
