HDPE Plastic Lathe Turning Parts Bead Blasting For Medical Industry
Medical Industry Precision Engineering Lathe Turning Parts Custom Cnc Aluminum Parts Cnc Turning Services
Product Description
At XinBo, we are competitive in custom short-runs, and mass production machining projects. Xinbo utilizes cutting edge performance machines and skilled machinist to tailor to each component’s specific tolerance requirements. Trust our team to ensure precise process control throughout design, production, and in hand delivery.
| Name | Custom manufacturing, CNC turning parts, CNC machined Plastic components, Custom CNC machining, Custom CNC turning. |
| Materials | Plastic Materials: ABS, PTFE, Nylon, POM, , PEEK, HDPE, etc. |
| Surface Treatment | Bead blasting, As machined etc. |
| Tolerance | ISO2768m, ISO2768f, +-0.1mm. |
| Testing equipment | CMM; Tool microscope; Automatic height gauge; Manual height gauge; Dial gauge; Plug Gauge; Micrometer; Marble platform. |
| Processing | CNC turning, CNC milling, CNC machining. |
| File Formats | Solid Works, Pro/Engineer, AutoCAD(DXF,DWG), IGS,STP, PDF,TIF etc. |
| Service Project | Free design review(DFM report), Production and technical service. |
| Roughness | Ra0.8, Ra1.6,Ra3.2, As machined. |
Machining Equipment
We have strategically acquired a robust fleet of precision equipment in order to enhance our ability to meet any customer request. Our professional operators and shop personnel have been trained and remain up-to-date on all mechanical processes.
| Name | Module | Range | Brand | Origin | Qty. | Precision |
| CNC Milling | VMC850/VMC1270 | V500-1270mm | Baoming/Baojia/Weikun | China | 26 | 0.02mm |
| CNC Milling | 4 axis | 200mm | BangBang | China | 5 | 0.005mm |
| CNC Milling | 5 axis | 200mm | BangBang | China | 1 | 0.005mm |
| CNC Milling | S500X1 | 500*400*300 | Brother | Japan | 2 | 0.005mm |
| Automatic Lathe | MC7036B/MC7020XE | 1-100mm | ZhongTai | China | 8 | 0.01mm |
| CNC Lathe | VT-17L | 215*470mm | Alex-Tech | Taiwan | 1 | 0.002mm |
| Turn-mill Combination | B0203-III | 1-46mm | TSGAMI | Japan | 4 | 0.002mm |
| Surface Grinder | PSGC-4080 AHR | 400*800mm | Proth | Taiwan | 2 | 0.002mm |
| Grinder | 520 | 200*400mm | Taizheng | China | 6 | 0.005mm |
| Mill Machine | 3# | 200*1000mm | Jietongda | China | 8 | 0.02mm |
| High Speed Wire Cut | 200*500mm | Jicheng | China | 4 | 0.02mm | |
| Medium Speed Wire Cut | DK7732C-C | 320*400mm | Baoma | China | 4 | 0.01mm |
| Laser Engrave Machine | G20 | Cherrywoolf | China | 1 | ||
| Other equipment:Drill machine, Tapper, Polisher, EDM puncher, Ultrasonic cleaner, Sand blaster machine, Saw machine, Magnetic grinder. |
||||||
Inspection Equipment
Xinbo Precision is ISO 9001:2015 Certified and strives to consistently meet our goals of continual improvement, on-time delivery and defect free products. Below is the inspection equipment list.
| Name | Module | Measuring range | Brand | Origin | Qty. | Precision |
| Height gauge | Hite-400 | 0-400mm | TESA | Swiss | 4 | 0.003um |
| Projector | VMS-3020 | 0-400mm | Video | Japan | 2 | 0.003um |
| CMM | CROMA 564 | 500*600*400mm | SERERN | Joint venture | 2 | 0.003um |
| Hardness tester | HR-150C | 20-88HRA,20-100HRB,20-70HRC | Rockwell | China | 2 | 0.5HR |
| Film thickness gauge | AR932 | 0-1700um | Smartsensor | China | 2 |
FAQ
Why Choose Xinbo for CNC Machining?
Iterate part designs quickly and accelerate product development with quick-turn parts. Our experienced engineering team will help spot any difficult to machine features before your design is sent to the manufacturing floor and save you from costly reworks further down the product development cycle.
Anodizing and Chromate Plating for Machined Parts?
Need a protective and aesthetic coating on your machined parts? We have your parts covered. Submit your order and get your parts in as little as seven days.
