Ra1.6 Complex CNC Machined Components Electroplating ISO2768F
Complex CNC Machined Components Custom Stainless Steel Parts Machining Stainless Steel Stainless Steel Custom Fabricator
Product Description
XinBo’s Machining Department consists of highly-skilled production machinists who have embraced the technology of advanced tooling and equipment. When it comes to machining, you want an experienced manufacturer. One that can handle large orders while having the agility to turn things on a dime.
XinBo’s machining experts understand your needs. Our team has decades of experience working with both manual tools and a variety of CNC machines. These machines include:
- CNC Lathes
- CNC Vertical Machining Centers
- CNC Horizontal Boring Mills
- CNC Gantry Mills
We know you have choices when it comes to your machining needs, but XinBo aims to provide services to meet all of your most demanding requests.
| Name | Custom manufacturing, CNC turning parts, CNC machined Plastic components, Custom CNC machining, Custom CNC turning. |
| Materials | Plastic, Steel, Brass, Aluminum, Titanium,Copper, Bronze |
| Surface Treatment | Bead blasting, As machined etc. |
| Tolerance | ISO2768m, ISO2768f, +-0.1mm. |
| Testing equipment | CMM; Tool microscope; Automatic height gauge; Manual height gauge; Dial gauge; Plug Gauge; Micrometer; Marble platform. |
| Processing | CNC turning, CNC milling, CNC machining. |
| File Formats | Solid Works, Pro/Engineer, AutoCAD(DXF,DWG), IGS,STP, PDF,TIF etc. |
| Service Project | Free design review(DFM report), Production and technical service. |
| Roughness | Ra0.8, Ra1.6,Ra3.2, As machined. |
Machining Equipment
We have strategically acquired a robust fleet of precision equipment in order to enhance our ability to meet any customer request. Our professional operators and shop personnel have been trained and remain up-to-date on all mechanical processes.
| Name | Module | Range | Brand | Origin | Qty. | Precision |
| CNC Milling | VMC850/VMC1270 | V500-1270mm | Baoming/Baojia/Weikun | China | 26 | 0.02mm |
| CNC Milling | 4 axis | 200mm | BangBang | China | 5 | 0.005mm |
| CNC Milling | 5 axis | 200mm | BangBang | China | 1 | 0.005mm |
| CNC Milling | S500X1 | 500*400*300 | Brother | Japan | 2 | 0.005mm |
| Automatic Lathe | MC7036B/MC7020XE | 1-100mm | ZhongTai | China | 8 | 0.01mm |
| CNC Lathe | VT-17L | 215*470mm | Alex-Tech | Taiwan | 1 | 0.002mm |
| Turn-mill Combination | B0203-III | 1-46mm | TSGAMI | Japan | 4 | 0.002mm |
| Surface Grinder | PSGC-4080 AHR | 400*800mm | Proth | Taiwan | 2 | 0.002mm |
| Grinder | 520 | 200*400mm | Taizheng | China | 6 | 0.005mm |
| Mill Machine | 3# | 200*1000mm | Jietongda | China | 8 | 0.02mm |
| High Speed Wire Cut | 200*500mm | Jicheng | China | 4 | 0.02mm | |
| Medium Speed Wire Cut | DK7732C-C | 320*400mm | Baoma | China | 4 | 0.01mm |
| Laser Engrave Machine | G20 | Cherrywoolf | China | 1 | ||
| Other equipment:Drill machine, Tapper, Polisher, EDM puncher, Ultrasonic cleaner, Sand blaster machine, Saw machine, Magnetic grinder. |
||||||
Inspection Equipment
Xinbo Precision is ISO 9001:2015 Certified and strives to consistently meet our goals of continual improvement, on-time delivery and defect free products. Below is the inspection equipment list.
| Name | Module | Measuring range | Brand | Origin | Qty. | Precision |
| Height gauge | Hite-400 | 0-400mm | TESA | Swiss | 4 | 0.003um |
| Projector | VMS-3020 | 0-400mm | Video | Japan | 2 | 0.003um |
| CMM | CROMA 564 | 500*600*400mm | SERERN | Joint venture | 2 | 0.003um |
| Hardness tester | HR-150C | 20-88HRA,20-100HRB,20-70HRC | Rockwell | China | 2 | 0.5HR |
| Film thickness gauge | AR932 | 0-1700um | Smartsensor | China | 2 |
FAQ
Why some of the parts have to be made by CNC machining instead of injection molding?
There are three main reasons, the first one is: some of the melt plastic has a very high viscosity(too thick) for the material flow to fill in the mold, for example PTFE.
The second reason is, some of the parts has to be have uneven wall thickness, that means it will have quality issue(for example sink mark, deformation or shot shot) if it is made by injection process. For CNC parts it don’t have the wall thickness limitation.
The third reason is: the quantity is small, it’s not worth to make a injection mould, the cost of the injection tooling at least thousands of USD, if the cost separated to couple of parts, the unit price will be very high.
Could the die casting aluminum parts have a cosmetic grade anodize finishing?
No, the die casting parts have silicon to improve the flow ability, the silicon will cause the uneven color of the surface. This challenge hasn’t be resolved yet.
