CNC Machined Metal Precision Engineered Components Sand Blast S45C Q235
Precision CNC Parts Precision Engineering Precision Components Machined Metal Parts Custom Cnc Parts
Shenzhen Xinbo Precision Parts Ltd., is committed to providing high quality CNC machining, finishing as well as heat treatment service including:
CNC milling
CNC turning
Swiss turning
Passivation
Tumbling
Alodine
Anodizing
Black Oxide
Chrome Electroplating
Galvanizing
Nitriding
Normalize
| Name | CNC Machining Service, Mechanical Parts, Professional Precision Cnc Machining Parts, CNC Parts |
| Materials | S45C, Q235, Q235B, 17-4, 17-4PH H900, 17-4PH H1150, SAE1018,SS304, SS301, SS316, SS316L |
| Surface Treatment | Electroplating, Polish, Sand Blast, Anodize, E-Coating, Passivation, Tumbling |
| Tolerance | ISO2768m, ISO2768f, +-0.01mm. |
| Testing equipment | CMM; Tool microscope; Automatic height gauge; Manual height gauge; Dial gauge; Screw gauge; Plug Gauge; Micrometer; Marble platform; Roughness measurement. |
| Processing | CNC turning, CNC machining. |
| File Formats | Solid Works, Pro/Engineer, AutoCAD(DXF,DWG), IGS,STP, PDF,TIF etc. |
| Service Project | Free design review(DFM report), Production and technical service. |
Machining Equipment
We have strategically acquired a robust fleet of precision equipment in order to enhance our ability to meet any customer request. Our professional operators and shop personnel have been trained and remain up-to-date on all mechanical processes.
| Name | Module | Range | Brand | Origin | Qty. | Precision |
| CNC Milling | VMC850/VMC1270 | V500-1270mm | Baoming/Baojia/Weikun | China | 26 | 0.02mm |
| CNC Milling | 4 axis | 200mm | BangBang | China | 5 | 0.005mm |
| CNC Milling | 5 axis | 200mm | BangBang | China | 1 | 0.005mm |
| CNC Milling | S500X1 | 500*400*300 | Brother | Japan | 2 | 0.005mm |
| Automatic Lathe | MC7036B/MC7020XE | 1-100mm | ZhongTai | China | 8 | 0.01mm |
| CNC Lathe | VT-17L | 215*470mm | Alex-Tech | Taiwan | 1 | 0.002mm |
| Turn-mill Combination | B0203-III | 1-46mm | TSGAMI | Japan | 4 | 0.002mm |
| Surface Grinder | PSGC-4080 AHR | 400*800mm | Proth | Taiwan | 2 | 0.002mm |
| Grinder | 520 | 200*400mm | Taizheng | China | 6 | 0.005mm |
| Mill Machine | 3# | 200*1000mm | Jietongda | China | 8 | 0.02mm |
| High Speed Wire Cut | 200*500mm | Jicheng | China | 4 | 0.02mm | |
| Medium Speed Wire Cut | DK7732C-C | 320*400mm | Baoma | China | 4 | 0.01mm |
| Laser Engrave Machine | G20 | Cherrywoolf | China | 1 | ||
| Other equipment:Drill machine, Tapper, Polisher, EDM puncher, Ultrasonic cleaner, Sand blaster machine, Saw machine, Magnetic grinder. | ||||||
Inspection Equipment
Commitment to quality has always been a driving force at XinBo Precision. Custom Manufacturing. Registered to the ISO 9001 quality standard since 2011, we’ve developed a quality policy that is the basis for our quality assurance program.
| Name | Module | Measuring range | Brand | Origin | Qty. | Precision |
| Height gauge | Hite-400 | 0-400mm | TESA | Swiss | 4 | 0.003um |
| Projector | VMS-3020 | 0-400mm | Video | Japan | 2 | 0.003um |
| CMM | CROMA 564 | 500*600*400mm | SERERN | Joint venture | 2 | 0.003um |
| Hardness tester | HR-150C | 20-88HRA,20-100HRB,20-70HRC | Rockwell | China | 2 | 0.5HRC |
| Film thickness gauge | AR932 | 0-1700um | Smartsensor | China | 2 | |
FAQ
What’s the difficulty to make a precision CNC machined plastic parts?
The difficult is the plastic part easily have warpage issue especially when the part is large or thin. The root cause is the stress generated in the machining process.
