0.05mm Small CNC Milling Parts Galvanized Chrome Electroplating Finishing
CNC Milling Parts Customized CNC Milling Precision Cnc Machined Parts
Product Description
Since our inception in 2011, Xinbo Precision has developed a reputation as an industry leader in engineering, manufacturing and product development.
Custom Machining Services. Our custom machining service is committed to precision quality, on time delivery, and overall excellence in the production of machined parts as required by our customers.
Xinbo Precision initially manufacturing components for the medical industry. Since then we have expanded to provide precision components for the medical, automotive, leisure, marine, oil and gas, cosmetics and defense industries.
| Name | Custom Manufacturing Service, CNC Turning Parts. |
| Materials | Aluminum, Copper, brass, stainless steel, steel, iron, zinc etc. Other Special Materials: PTFE/Nylon/POM/Titanium//PEEK, etc. |
| Surface Treatment | Anodizing, Hard Anodizing, Brushing, Galvanized, Laser Engraving, Silk printing, Polishing, Powder Coating, Passivation, Alodine, Barrel Grinding, Trommelen, Chemical Conversion, Bead Blasting, Satin Finish, Chrome Plating etc. |
| Tolerance | ISO2768m, ISO2768f, 0.005mm. |
| Testing equipment | CMM; Tool Microscope; Automatic Height Gauge; Manual Height gauge; Dial Gauge; Screw Gauge; Plug Gauge; Micrometer; Marble Platform; Roughness Measurement |
| Processing | CNC Turning, CNC milling, CNC machining, Grinding, EDM Wire Cutting, Sink EDM |
| File Formats | Solid Works, Pro/Engineer, AutoCAD(DXF,DWG), IGS,STP, PDF,TIF etc. |
| Service Project | Free Design Review(DFM report), Production And Technical Service. |
| Roughness | Ra0.4, Ra0.8, Ra1.6,Ra3.2, As machined. |
Machining Equipment
| Name | Module | Range | Brand | Origin | Qty. | Precision |
| CNC Milling | VMC850/VMC1270 | V500-1270mm | Baoming/Baojia/Weikun | China | 26 | 0.02mm |
| CNC Milling | 4 axis | 200mm | BangBang | China | 5 | 0.005mm |
| CNC Milling | 5 axis | 200mm | BangBang | China | 1 | 0.005mm |
| CNC Milling | S500X1 | 500*400*300 | Brother | Japan | 2 | 0.005mm |
| Automatic Lathe | MC7036B/MC7020XE | 1-100mm | ZhongTai | China | 8 | 0.01mm |
| CNC Lathe | VT-17L | 215*470mm | Alex-Tech | Taiwan | 1 | 0.002mm |
| Turn-mill Combination | B0203-III | 1-46mm | TSGAMI | Japan | 4 | 0.002mm |
| Surface Grinder | PSGC-4080 AHR | 400*800mm | Proth | Taiwan | 2 | 0.002mm |
| Grinder | 520 | 200*400mm | Taizheng | China | 6 | 0.005mm |
| Mill Machine | 3# | 200*1000mm | Jietongda | China | 8 | 0.02mm |
| High Speed Wire Cut | 200*500mm | Jicheng | China | 4 | 0.02mm | |
| Medium Speed Wire Cut | DK7732C-C | 320*400mm | Baoma | China | 4 | 0.01mm |
| Laser Engrave Machine | G20 | Cherrywoolf | China | 1 | ||
| Other equipment:Drill machine, Tapper, Polisher, EDM puncher, Ultrasonic cleaner, Sand blaster machine, Saw machine, Magnetic grinder. | ||||||
Inspection Equipment
| Name | Module | Measuring range | Brand | Origin | Qty. | Precision |
| Height gauge | Hite-400 | 0-400mm | TESA | Swiss | 4 | 0.003um |
| Projector | VMS-3020 | 0-400mm | Video | Japan | 2 | 0.003um |
| CMM | CROMA 564 | 500*600*400mm | SERERN | Joint venture | 2 | 0.003um |
| Hardness tester | HR-150C | 20-88HRA,20-100HRB,20-70HRC | Rockwell | China | 2 | 0.5HRC |
| Film thickness gauge | AR932 | 0-1700um | Smartsensor | China | 2 | |
FAQ
Question: What components need the CNC machining process?
Box-type parts, box-type parts generally refers to more than one hole system, internal cavity, in the direction of length, width and height of a certain proportion of the parts.
This type of parts in the machine tool, automotive, aircraft manufacturing and other industries with more. Box class parts are generally required for multi-station hole system and plane processing, high tolerance requirements, especially the shape tolerance requirements are more stringent.
Machining center for box-type parts, when processing more stations, the table needs to be rotated several times to complete the angle of the parts, the general choice of horizontal boring and milling machining center.
When processing fewer stations, and the span is not large, you can choose the vertical machining center, from one end of the processing.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
