Thru Axle Disc Brak 142mm Road Bike Carbon Fiber hidden cables
Thru Axle Disc Brak 142mm Road Bike Carbon Fiber Hidden Cables
Carbon Fiber Road Bike Features:
> Super light Carbon fiber T1000
> Internal cable routing system, easy for cables slip through,
> Tapered head tube design, together with the tapered and straight fork design, which offers a better stiffness for steering and acceleration.
> Strong chain stay and seat stay design, which offers super stiffness and strength for racing
> DI2 system available too
> Maximized stiffness-to-weight ratio design, have a excellent balance for weight-stiffness-strength.
Component of Carbon Fiber Road Bike:
Cyclonepro is a bike built for performance. Its driving precision, together with the SHIMANO system that cancels vibrations, guarantees unparalleled control of the vehicle. Perfect power transmission means that every watt unloaded on the pedals will get you closer to the finish line faster than your opponents. If you want to get to the top of your favorite sport, Cyclonepro is the perfect way to accompany you.
| Bike Model | CYCLONEpro -Disc |
| ConfRev | R8020-22S, carbon wheel |
| Wheel Size | 700C |
| Frame Height | 45cm / 48cm / 51cm / 54cm |
| Bike Color | BlackRed / Red / WhiteRed / Black / TiGray / CementGray / Silver / Blue / Yellow / Orange, Holographic color(Red / Black) |
| Net Weight | 8.4KG |
| Frame | CYCLONEpro(Disc&thru-axle 12×142mm), high modulus Carbon,EPS,Racing,full Inner-Cables,Gloss or Matte,UV embossing decals |
| Handelbar Sets | TW, high modulus Carbon, Integrated Handlebar&Stem(420*90mm),UV embossing water decals, full Inner-Cables |
| Seat Post | High modulus Carbon, UV decals |
| Clamps | Hidden Screw Fit to Frame |
| Fork | CYCLONEpro, high modulus Carbon,700C,UV embossing decals, Disc&thru-axle 12×100mm |
| Head Sets | TW, Alu alloy CNC with sealed-Bearings 52*52mm |
| Washer | Carbon 3K, 3×28.6×10mm |
| Derailleur Handle | SHIMANO UT/R8020-22S (hydr disc Handle) |
| Front Derailleur | SHIMANO UT/R8000 |
| Rear Derailleur | SHIMANO UT/R8000 |
| Cranksets | SHIMANO UT/R8000, 34-50T |
| Cassettes | SHIMANO UT/R8000-11S,11-28T |
| Chain | SHIMANO HG701-11S |
| BB | BB86×46×24mm, pressed, Alu alloy CNC&Hollow, with sealed bearings |
| Brake | SHIMANO UT/R8070 Hydr+PRO float disc 140 |
| Hubs | TW Alu alloy in Carbon, 4-sealed Bearings,Slotted,F20-R24 holes,Disc&thru-axle F12×100_R12×142mm |
| Rim | RS ultra-light carbon 3K twill,Clincher,W25×H50mm×700C, UV decals |
| Spoke | Pillar, Stainless Pro, Flat 14G,straight |
| Tyre | INNOVA-PRO, Smoothie, 60TPI, 700*25C, Skin-color edge |
| Belt | Colorful with vents,Comfortable&Skid resistant |
| Saddle | TW, comfortable&lightweight for racing |
| Pedals | RS ultra-light Alu alloy CNC with sealed-Bearings for Road |
| Cables | JAGWIRE |
| Accessories | Standard safety reflector for Handelbar,Seat post,Front wheel,Rear wheel |
| Superlight Alu alloy bottle cage+Tools | |
| TWITTER Manual+Warranty card |
Colors:BlackRed / Red / WhiteRed / Black / TiGray / CementGray / Silver / Blue / Yellow / Orange
Angles:
Size:700C*45cm / 48cm / 51cm / 54cm
| size | A | B | C | D | E | F | G | H | I | J | K |
| BB Center to Top of Seat Tube | Effective Top Tube Horizontal | BB offset | Chainstay Length | Seat angle | Head Angle | Front Center | Head Tube Length | Fork Offset | Reach | Stack | |
| mm | mm | mm | mm | ° | ° | mm | mm | mm | mm | mm | |
| XS - 45cm | 450 | 505 | -74 | 408 | 74.3 | 71.2 | 570 | 100 | 55 | 363 | 506 |
| S - 48cm | 480 | 520 | -74 | 408 | 74.3 | 71.2 | 588 | 114 | 55 | 374 | 518 |
| M - 51cm | 510 | 538 | -74 | 408 | 74.3 | 71.2 | 607 | 130 | 55 | 388 | 534 |
| L - 54cm | 540 | 550 | -74 | 408 | 74.3 | 71.2 | 620 | 150 | 55 | 394 | 553 |
Details of EPS technology:
1. Strong carbon fiber shell, durable frame, strong and light weight.
2.the finished frame has better hardness, toughness,strength to weight ratio, tightness and other qualities.
3.Significantly improve the stability and smoothness of the lamination
and joint between the inner cavity of the frame.
4 greatly reduce the excessive concentration of internal stress of the frame, thelength of the finished frame life, stable quality
5.The finished frame has a smooth appearance.
Packing:
1.Material:Carton outside with Plastic inside package.
2.Carton Size:140CM*75CM*20CM
3.Container Quantity:20GP-120pcs-125pcs;40HQ-290pcs-296pcs
Company Details:
Twitter is a high-end brand. Our product range from carbon bike, bicycle accessories and cycling equipment. Our factory covers area over 14000 square meter, with 150 employees, we can produce all type of bike up to 30000 sets monthly, and carbon frame 80000 sets. we had 6 automatic electrostatic spraying line, pre-treatment, frame assembly equipment and other complete original German technology. We make carbon frame in house and only use carbon fabric material T700 or T800 from TORAY Japan. Since its inception, it has quickly revolutionized the Chinese bicycle industry with original German technology, cutting-edge professionals and consistent German quality. Our main partner is Shimano, Michelin, Maxxis, Fizik, Fox racing etc, so we can design and delivery high quality of bike to our customer. KOOTU has developed into a comprehensive modern enterprise integrating R&D, production, sales and service. 90% of our products are exported to France, Italy, South Korea, Japan, Saudi Arabia,Russia, Iran, Thailand, Malaysia, Vietnam, Myanmar, Chile, Nepal,Angola,Colombia,Guatemala,Panama and other countries. With 12 years experience in bike industry, we can provide most professional and cost effective bike to our clients. our sales team always put customer satisfaction in first priority, support and help to growing our customers' business.
