Programmable Xenon Arc Weathering Test Chamber for Accelerated Sunlight Aging and Climate Simulation
Price:
Negotiable
MOQ:
1
Delivery Time:
30 Days
Brand:
Sinuo
Product Description
Xenon Arc Weathering Test Chamber for Accelerated Light Aging and Sunlight Simulation Testing
Compliance Standards
- The equipment complies with the following standards:
- GB/T 16422.2-2014 — Plastics — Exposure to laboratory light sources
- ISO 4892-2 — Plastics — Methods of exposure to laboratory light sources — Part 2: Xenon-arc lamps
- ISO 11341 — Paints and varnishes — Artificial weathering and exposure to artificial radiation — Filtered xenon-arc radiation
- AATCC TM16 — Colorfastness to Light
- AATCC 169 — Weather Resistance of Textiles: Xenon Arc Method
- GB/T 8427-2008 — Textiles — Tests for color fastness — Color fastness to artificial light: Xenon arc
Product Overview
Designed for artificial weathering and light aging tests simulating natural sunlight exposure. The chamber is suitable for automotive interiors, plastics, paints, coatings, electronic instruments, textiles, printing and dyeing materials, dyes, decorative materials, wood flooring, safety helmets, leather, petrochemical products, rubber, and other related materials.
By setting xenon lamp irradiance, temperature, humidity, water spray, and light/dark cycles inside the chamber, the equipment provides standardized simulated natural environments to evaluate material performance changes such as fading, aging, softening, hardening, and cracking.
Technical Parameters
| Item | Specification |
|---|---|
| Model | SN884B |
| Test Chamber Size (D*W*H) | 490 * 790 * 400 mm |
| Overall Dimensions (D*W*H) | 1130 * 1020 * 1800 mm |
| Lamp Type | Air-cooled xenon arc lamp |
| Lamp Lifetime | ≥ 1200 hours |
| Irradiance Control Wavelengths | 340 nm, 420 nm, 300–400 nm |
| Irradiance Range | 0.35–1.00 W/m² @340 nm; 0.45–2.40 W/m² @420 nm |
| Irradiance Control | Built-in solar eye, closed-loop PID automatic adjustment |
| Filter System | Special glass filters simulating daylight or window glass environments |
| Air Temperature Range | 35–65 °C (adjustable) |
| Black Panel Temperature (BPT) | Light cycle 55–100 °C; dark cycle 35–65 °C |
| Black Standard Temperature (BST) | Light cycle 60–110 °C; dark cycle 35–65 °C |
| Temperature Deviation | ±3 °C |
| Humidity Range | Light cycle 20–75% RH; dark cycle 45–95% RH |
| Humidity Deviation | ±5% RH |
| Irradiation Area | 3240 cm² |
| Sample Inclination | 10° |
| Sample Capacity | Standard finished parts or 3D specimens |
| Light/Dark Cycle | 0–9999 h programmable |
| Spray Cycle | 0–9999 h programmable |
| Spray Method | Surface spray |
| Number of Lamps | 3 units |
