15675LM 17325LM 18975LM 20625LM LED Linear Highbay Light for Warehouse Illumination

Price Negotiable
Price: Negotiable
MOQ: 100pcs
Delivery Time: 30 day(s)
Brand: Noonlight
Product Description

Product Description:

The Noonlight Linear Highbay Led fixture is a versatile solution that is applicable to a wide range of settings and mounting heights. Its flexibility lies in its various lumen packages that provide an excellent option for a one-for-one swap-out of a traditional fluorescent or metal halide high bay system.

With its high-quality lighting performance and energy efficiency, the Noonlight Linear Highbay Led fixture is the perfect solution to accommodate all your lighting needs. In addition, its efficient design ensures that energy consumption is kept low while still providing optimal lighting output.

Whether you need to illuminate a commercial, industrial or warehouse space, the Noonlight Linear Highbay Led fixture is a reliable solution to provide excellent lighting performance and energy savings.

Features:

Our product has achieved a high lighting effect of up to 165LM/W, which means it produces bright light and ensures energy efficiency.

The front access junction box design makes maintenance easy and convenient, no need to disassemble the whole system.

Our product also comes with plugable PIR and motion sensors, including Zhaga PIR and Motion sensors, providing a user-friendly experience.

With one driver for all wattages ranging from 30-320W, the cost is reduced, and the dimming is smoother, giving a seamless experience for users.

Our product minimizes the stock as one SKU can cover up to 12 models, simplifying inventory management.

Our product provides a universal input voltage of 120-277Vac/347Vac to 347-480Vac, offering flexibility in usage.

Class P Programmable LED Driver with 0-10V Dimming, Dim to off feature, guarantees a customized experience and convenience for users.

Technical Parameters:

Luminous Flux 15675LM - 17325LM - 18975LM - 20625LM
Color Temperature 4000K / 5000K
Light Source SMD2835
Power 95W - 105W - 115W - 125W
Lifespan 50,000hrs
CRI Ra>80
Input Voltage 100-277VAC Or 100-347VAC Or 347-480VAC
Material White Powder Painted Steel
Warranty 5 Years
Working Temperature -20~+45℃



Accessories





Bi-level 12V PIR Sensor/PIR Sensor with Daylight Harvesting



Specification

  • Dual PD Technology: can identify daylight and artificial light.
  • Input Voltage: 12VDC Output: 0-10V, 25mA sinking current
  • Mounting Height: Max. 40ft. Detection Range: 30ft @ 40ft height in diameter
  • IR remote commissioning: easy setting via remote controller
  • Photocell available



15W or 30W UL Listed Emergency Backup



  • Listed for field Instllation-UL924 & CSA C22.2 NO. 141
  • Input: 120-277VAC/347VAC 50/60Hz
  • Output: 25-50VDC, 15 or 30W
  • Illumination Time: 90min
  • Battery Type:Li-ion
  • Battery Recharge Time: 24Hrs
  • Surge Protection: 3KV
  • Protection:
  • Input over-current Protection (Fuse)
  • Output over-voltage Protection
  • Output Low Voltage Protection
  • Output Short Circuit Protection
  • Working Temp.: 10℃ to 50℃

Applications:

Schools, offices, conference room, hospitality etc.
