Brighter White Powder Steel LED Grid Lighting Max 125LM/W Luminous Efficacy 5000LM
Product Description:
- Very easy for pendent, mounted, recessed, and T-grid installation
- Modular light source design
- Smart and flexible choice of light source quantity
- Various of lighting beam angles
- Very low UGR<22 / UGR<19 for option
- Standard length or customized length available
DIMENSION
Features:
The product is compatible with different voltages, including 120~277VAC, 120~347VAC, and 220~240VAC. This allows for wider range of use in different regions with different grid systems. Moreover, the product comes in various power consumption options, ranging from 20W, 30W, 40W, to 60W, providing customers with flexible choices that suit various illumination purposes.
The product also boasts two different light efficiency options: 125Lm/W and 160 Lm/W. This means customers can decide on the amount of light output they want without sacrificing energy consumption. Nonetheless, regardless of which option the customer chooses, the product has four different beam angles to choose from: 30°, 60°, 90°, and 120°, offering versatility in lighting design.
To further fulfill customers' needs, the product is designed to work with different dimming systems, including 0-10V (dual channel), Dali 2, as well as Non-dim. This means customers can optimize the brightness of their lighting according to their preferences and requirements.
The product has also been awarded with ETL, DLC, CE, RoHS certifications, indicating its compliance with both safety and environmental protection regulations. Last but not least, the product comes with a 5-year warranty, assuring customers of its quality and performance over extended period of time.
Specification
| Model No | ETL | Input Voltage | Wattage | LPW | Lumen | Beam Angle |
| N-GL-22-20W-2L-DF | YES | 120-277VAC 120-347VAC 220-240VAC |
20W(Max) | 160LM/W(Max) | 3200LM(Max) | 120° |
| N-GL-22-20W-2L-[30,60,90] | 125LM/W(Max) | 2500LM(Max) | 30°,60°,90° | |||
| N-GL-22-30W-3L-DF | YES | 120-277VAC 120-347VAC 220-240VAC |
30W(Max) | 160LM/W(Max) | 4800LM(Max) | 120° |
| N-GL-22-30W-2L-[30,60,90] | 125LM/W(Max) | 3750LM(Max) | 30°,60°,90° | |||
| N-GL-24-40W-2L-DF | YES | 120-277VAC 120-347VAC 220-240VAC |
40W(Max) | 160LM/W(Max) | 6400LM(Max) | 120° |
| N-GL-24-40W-2L-[30,60,90] | 125LM/W(Max) | 5000LM(Max) | 30°,60°,90° | |||
| N-GL-24-60W-1L-DF | YES | 120-277VAC 120-347VAC 220-240VAC |
60W(Max) | 160LM/W(Max) | 9600LM(Max) | 120° |
| N-GL-24-60W-1L-[30,60,90] | 125LM/W(Max) | 7500LM(Max) | 30°,60°,90° | |||
| N-GL-14-20W-1L-DF | YES | 120-277VAC 120-347VAC 220-240VAC |
20W(Max) | 160LM/W(Max) | 3200LM(Max) | 120° |
| N-GL-14-20W-1L-[30,60,90] | 125LM/W(Max) | 2500LM(Max) | 30°,60°,90° | |||
| N-GL-14-40W-1L-DF | YES | 120-277VAC 120-347VAC 220-240VAC |
40W(Max) | 160LM/W(Max) | 6400LM(Max) | 120° |
| N-GL-14-40W-1L-[30,60,90] | 125LM/W(Max) | 5000LM(Max) | 30°,60°,90° | |||
| N-GL-4F-30W-1L-DF | YES | 120-277VAC 120-347VAC 220-240VAC |
30W(Max) | 160LM/W(Max) | 4800LM(Max) | 120° |
| N-GL-4F-30W-1L-[30,60,90] | 125LM/W(Max) | 3750LM(Max) | 30°,60°,90° |
Accessories
Specification:
Input Voltage:100~277Vac/347Vac 50/60Hz , Input
Current:100mA max. Input Power Rating:7W max. Output Voltage:25V~230Vdc
Warranty:5 Years
Ambient Temp:Li-ion:32~122°F(0~50°C)
Ni-MH: 41~149°F(5~65°C)
Applications:
Gymnasium,Farm,Stadium,Warehouse,Factory,Airport,Parking lot,Smelter,Tunnel
