4000lm 25W LED Stairwell Lights Suspension Mounted 130lm/W
4FT 25W 130lm/W 4000lm LED Corner Stairwell Light, 3000K 3500K 4000K 5000K Tunable
- 4” LED Corner LED Stairwell fixture is a fan style linear led fixture, available with 2ft, 4ft and 8ft long.
- Integral with new trend of field-adjustable functions provide our customers greater flexibility on wattages and color temperatures.
- Optional Occupancy Sensor & Built-in Emergency Backup
- Ideal for stairwell, passageway and general lighting etc.
- CRI>80, CCT Tunable, 3000K, 3500K, 4000K and 5000K
- Minimize stock, 1 SKU can cover max. of 16 models.
- Various Lens Option: Clear, Frosted,
- 5-100% 0-10V dimmable, flicker free, Dim to off.
- Built-in Emergency Driver Option.
| Model No | DLC | Input Voltage | Wattage | Lens | CRI/CCT | Rated Lumen @ 50K |
Rated Efficancy @ 50K |
Viewing Angle | Replacing |
| N-LC4-2FT-40W-1XX- [Blank, S1, S2]-C-FL- CT-FA-Z |
YES |
100-277VAC or 100-347VAC
|
40 |
Frosted/ Clear
|
Ra>80, 30K 35K 40K 50K |
5130 | 126 | 180° |
2 X T5HO 4FT 54W 3 X T8 4FT 32W |
| N-LC4-2FT-25W-1XX- [Blank, S1, S2]-C-FL- CT-FA-Z |
YES |
100-277VAC or 100-347VAC |
25 |
Frosted/ Clear |
Ra>80, 30K 35K 40K 50K |
3300 | 130 | 180° |
2 X T5HO 4FT 54W 3 X T8 4FT 32W |
| N-LC4-2FT-18W-1XX- [Blank, S1, S2]-C-FL- CT-FA-Z |
YES |
100-277VAC or 100-347VAC |
18 |
Frosted/ Clear |
Ra>80, 30K 35K 40K 50K |
2340 | 132 | 180° |
2 X T5HO 4FT 54W 3 X T8 4FT 32W |
| N-LC4-2FT-12W-1XX- [Blank, S1, S2]-C-FL- CT-FA-Z |
YES |
100-277VAC or 100-347VAC |
12 |
Frosted/ Clear |
Ra>80, 30K 35K 40K 50K |
1650 | 128 | 180° |
1 X T8 4FT 32W
|
Bi-level 12VDC 0-10V Motion Sensor
Specification
- Dual PD Technology: can idenify daylight and artificatial light.
- Input Voltage: 12VDC
- Output: 0-10V, 25mA sinking current
- Mouting Height: Max. 40ft.
- Detection Range: 30ft @ 40ft height in diameter
- IR remote commissing: easy setting via remote controller
- Photocell available
Default Setting/Setting
- Sensitivity: 100%/25%, 50%, 75%, 100%
- Daylight Sensor: Disable/Ambient Learn, 10lux, 30lux, 50lux, 100lux, 300lux, 500lux, Disable
- Hold Time: 5min/10s, 1min, 5min, 5min, 10min, 15min, 20 min, 30min, 60 min
- Twilgith Time: never turn off/1min, 30min, 1h, never tun off
- Twilight Level: 20%/off, 10%, 20%, 50%
HOW TO CHANGE THE CCT IN THIS FIXTURE
|
CCT Tunable Slide Switch Position |
|
|
Position/Group |
CCT |
|
CCT1 |
3000K |
|
CCT2 |
3500K |
|
CCT3 |
4000K |
|
CCT4 |
5000K |
Stairwell Lighting, Passageway Lighting, Corridor Lighting, Shop Lighting, Strip Lighting, Low Bay Lighting, Warehouse Lighting
