Suspended Mounted Linear Stair Lighting Wall Light Fixture For Stairwell 18W 130lm/W 2400lm
4FT 18W 130lm/W 2400lm 42-Watt Equivalent LED Corner Stairwell Light, 4 CCT in 1, Suspended Mounted
- 4” LED Corner LED Stairwell fixture is a fan style linear led fixture, available with 2ft, 4ft and 8ft long.
- Integral with new trend of field-adjustable functions provide our customers greater flexibility on wattages and color temperatures.
- Optional Occupancy Sensor & Built-in Emergency Backup
- Ideal for stairwell, passageway and general lighting etc.
- UP TO 135LM/W
- CLASS P Programmable LED Driver, 4 Step Power Adujustable,
- CRI>80, CCT Tunable, 3000K, 3500K, 4000K and 5000K
- Minimize stock, 1 SKU can cover max. of 16 models.
- An auxiliary to connect low voltage sensor/BLE or other IOT network.
- Various Lens Option: Clear, Frosted,
- 5-100% 0-10V dimmable, flicker free, Dim to off.
- Built-in PIR Sensor and Motion Sensor Options.
- Built-in Emergency Driver Option.
- L70>50,000hrs, 5 year warranty.
| Model No | DLC | Input Voltage | Wattage | Lens | CRI/CCT | Rated Lumen @ 50K |
Rated Efficancy @ 50K |
Viewing Angle | Replacing |
| N-LC4-2FT-40W-1XX- [Blank, S1, S2]-C-FL- CT-FA-Z |
YES |
100-277VAC or 100-347VAC
|
40 |
Frosted/ Clear
|
Ra>80, 30K 35K 40K 50K |
5130 | 126 | 180° |
2 X T5HO 4FT 54W 3 X T8 4FT 32W |
| N-LC4-2FT-25W-1XX- [Blank, S1, S2]-C-FL- CT-FA-Z |
YES |
100-277VAC or 100-347VAC |
25 |
Frosted/ Clear |
Ra>80, 30K 35K 40K 50K |
3300 | 130 | 180° |
2 X T5HO 4FT 54W 3 X T8 4FT 32W |
| N-LC4-2FT-18W-1XX- [Blank, S1, S2]-C-FL- CT-FA-Z |
YES |
100-277VAC or 100-347VAC |
18 |
Frosted/ Clear |
Ra>80, 30K 35K 40K 50K |
2340 | 132 | 180° |
2 X T5HO 4FT 54W 3 X T8 4FT 32W |
| N-LC4-2FT-12W-1XX- [Blank, S1, S2]-C-FL- CT-FA-Z |
YES |
100-277VAC or 100-347VAC |
12 |
Frosted/ Clear |
Ra>80, 30K 35K 40K 50K |
1650 | 128 | 180° |
1 X T8 4FT 32W
|
4W or 8W UL Listed Emergency Backup
- Listed for field Instllation-UL924 & CSA C22.2 NO. 141
- Input: 120-277VAC/347VAC 50/60Hz
- Output: 25-50VDC, 15 or 30W
- Illumination Time: 90min
- Battery Type:Li-ion/Ni-MH
- Battery Recharge Time: 24Hrs
- Surge Protection: 3KV
- Protection:
- Input over-current Protection (Fuse)
- Output over-voltage Protection
- Output Low Voltage Protection
- Output Short Circuit Protection
- Working Temp.: 10℃ to 50℃
HOW TO CHANGE THE CCT IN THIS FIXTURE
|
CCT Tunable Slide Switch Position |
|
|
Position/Group |
CCT |
|
CCT1 |
3000K |
|
CCT2 |
3500K |
|
CCT3 |
4000K |
|
CCT4 |
5000K |
Stairwell Lighting, Passageway Lighting, Corridor Lighting, Shop Lighting, Strip Lighting, Low Bay Lighting, Warehouse Lighting
