4950-8250 Lumen LED Linear High Bay Lights 30W 35W 40W 50W Adjustable
4950-8250 Lumen Power Switchable, 175W HID Equivalent Linear LED High Bay Fixture
- Noonlight Linear Highbay Led fixture is the perfect solution for a wide variety of applications and mounting heights. Its multiple lumen packages make it an ideal choice as a one for one replacement of conventional fluorescent and metal halide high bay systems.
- Available in 120-347VAC or 347-480VAC Class P Programmable LED Driver, 0-10V Dimming, Dim to Off
- 1x4 linear high bay One and Only Cutting Edge Class 2 Driver Techonology,
- 1 Driver only for All of Power Up to 320W with Class 2 Certificated(100-347VAC only)
- 4 Step Power Adujustable, and 3 CCT Tunable(Optional), minimize stock, 1 SKU can cover max. of 12 models.
- Front Access Door for Easy Maintenance
- Plugable PIR Sensor and Motion Sensor, Zhaga PIR & Motion Sensor
- CCT and Power linear high bay Built-in Emergency Driver Option
| Model No | DLC | Input Voltage | Wattage | Lens | CCT | Rated Lumen @ 50K |
Rated Efficancy @ 50K |
Viewing Angle | Replacing |
| N-HBL-12-30W-8XX-F-CTPA-[Blank,HV]-SN |
Pending
|
100-277VAC or 100-347VAC
|
30 |
Frosted/ Clear
|
40/45/50K Tunable or 4000K, 5000K
|
4950 | 165 | 120° |
100W MH, 4-lamp T8 NBF
|
| N-HBL-12-35W-8XX-F-CTPA-[Blank,HV]-SN | 35 | 5775 | |||||||
| N-HBL-12-40W-8XX-F-CTPA-[Blank,HV]-SN | 40 | 6600 | |||||||
| N-HBL-12-50W-8XX-F-CTPA-[Blank,HV]-SN | 50 | 8250 | |||||||
| N-HBL-12-50W-8XX-F-CTPA-[Blank,HV]-SN |
Pending
|
100-277VAC or 100-347VAC
|
50 |
Frosted/ Clear
|
40/45/50K Tunable or 4000K, 5000K |
8250 | 165 | 120° |
175W MH, 4-lamp T8 HBF, 2-lamp T5HO
|
| N-HBL-12-55W-8XX-F-CTPA-[Blank,HV]-SN | 55 | 9075 | |||||||
| N-HBL-12-60W-8XX-F-CTPA-[Blank,HV]-SN | 60 | 9900 |
200W MH, 6-lamp T8 NBF
|
||||||
| N-HBL-12-65W-8XX-F-CTPA-[Blank,HV]-SN | 65 | 10725 | |||||||
| N-HBL-12-60W-8XX-F-CTPA-[Blank,HV]-SN |
Pending
|
100-277VAC or 100-347VAC
|
60 |
Frosted/ Clear |
40/45/50K Tunable or 4000K, 5000K |
9900 | 165 | 120° |
250W MH, 6-lamp T8 HBF, 4-lamp T5HO
|
| N-HBL-12-70W-8XX-F-CTPA-[Blank,HV]-SN | 70 | 11550 | |||||||
| N-HBL-12-75W-8XX-F-CTPA-[Blank,HV]-SN | 75 | 12375 |
400W MH, 6-lamp T5HO
|
||||||
| N-HBL-12-85W-8XX-F-CTPA-[Blank,HV]-SN | 85 | 14025 | |||||||
| N-HBL-12-95W-8XX-F-CTPA-[Blank,HV]-SN |
Pending
|
100-277VAC or 100-347VAC or 347-480VAC |
95 |
Frosted/ Clear
|
40/45/50K Tunable or 4000K, 5000K |
15675 | 165 | 120° |
400W MH, 6-lamp T5HO
|
| N-HBL-12-105W-8XX-F-CTPA-[Blank,HV]-SN | 105 | 17325 | |||||||
| N-HBL-12-115W-8XX-F-CTPA-[Blank,HV]-SN | 115 | 18975 |
575W MH, 10-lamp T8 HBF |
||||||
| N-HBL-12-125W-8XX-F-CTPA-[Blank,HV]-SN | 125 | 20625 |
750W MH, 8-lamp T5HO |
||||||
| N-HBL-12-130W-8XX-F-CTPA-[Blank,HV]-SN | Pending |
100-277VAC or 100-347VAC or 347-480VAC
|
130 |
Frosted/ Clear |
40/45/50K Tunable or 4000K, 5000K |
21450 | 165 | 120° |
875W MH, 10-lamp T5HO |
| N-HBL-12-140W-8XX-F-CTPA-[Blank,HV]-SN | 140 | 23100 | |||||||
| N-HBL-12-155W-8XX-F-CTPA-[Blank,HV]-SN | 155 | 25575 |
1000WMH, 12-lamp T5HO |
||||||
| N-HBL-12-170W-8XX-F-CTPA-[Blank,HV]-SN | 170 | 28050 |
1x4 linear high bay Suitable for Surface mounted, suspended mounted.
HOW TO CHANGE THE WATTAGE & CCT IN THIS FIXTURE
| Power Adjustable Slide Switch Position | ||||
| Size/Positon | 0 | 1 | 2 | 3 |
| 1X2 | 30W | 35W | 40W | 50W |
| 1X2 | 50W | 55W | 60W | 65W |
| 1X2 | 60W | 70W | 75W | 85W |
| 1X2 | 95 | 105 | 115 | 125 |
| 1X2 | 130 | 140 | 155 | 170 |
| CCT Tunable Slide Switch Position | |
| Position/Group | CCT |
| Low | 4000K |
| Middle | 4500K |
| High | 5000K |
Schools, offices, conference room, hospitality etc.
