Horizontal 2.5MPA manual sintered screen filter


Describe:

JSYL series equipment can filter out solid particles in various water and low-viscosity liquids (such as machined coolants), reduce liquid turbidity, purify water quality, reduce system dirt, bacteria, algae, rust, etc., and keep materials clean. In order to meet the requirements of system operation and downstream processes for liquid cleanliness, it can also be used to protect downstream key equipment from particle blockage, abrasion or fouling, and improve the operating efficiency and life of key equipment.

Features:

When water flows through the filter, the mechanical impurities in the water will be trapped by the filter screen. When the surface area of the filter screen increases and the pressure reaches 0.04MPa, the differential pressure switch sends a signal, and the PLC sends a command to start the drive motor and open the drain valve. The impurities deposited on the filter are brushed down by the rotating brush and discharged from the drain. The entire washing and sewage process does not require manual operation and stop. In addition, the filter is also equipped with timed/manual cleaning and drainage to ensure that water can be discharged safely and reliably under any circumstances.

Applicable industry:

Circulating water filtration, reclaimed water reuse, advanced wastewater treatment filtration, central air conditioning, boiler backwater filtration, groundwater, surface water, swimming pools, landscape water purification The breeding water is filtered.
