Home Use Polycrystalline Solar Panel 435W 440W 445W 450W 455W
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
LH
Product Description
435w/440w/445w/450w/455w photovoltaic solar panels solar panel for home use
Features:
- Excellent module efficiency up to: 21.50%
- IP68 junction box for long-term weather endurance
- Heavy snow load up to 5400Pa, wind load up to 3600Pa
- PID: Selected material and stringent quality system ensure PID free
- Applicable to harsh environment of deserts, farmlands and seasides
- Much lower risk of Hot Spot
WARRANTY
From the 2nd year to the 30th year,the average annual power decline will be no more than 0.5%.
Linear power output warranty
-12 years minimum 92% power output
-30 years minimum 83% power output
Product warranty on materials and workmanship According to the applicable rise Warranty Statement
| ELECTRICAL SPECIFICATION | Unit | LH-435MH | LH-440MH | LH-445MH | LH-450MH | LH-455MH |
| Maximum Power (Pmax) | W | 435 | 440 | 445 | 450 | 455 |
| Module Efficiency | % | 20 | 20.2 | 20.5 | 20.7 | 20.9 |
| Open Circuit Voltage (Voc) | V | 48.7 | 48.9 | 49.1 | 49.3 | 49.5 |
| Short Circuit Current (Isc) | A | 11.39 | 11.46 | 11.53 | 11.6 | 11.66 |
| Maximum Power Voltage (Vmp) | V | 40.89 | 41.1 | 41.3 0 | 41.5 | 41.7 |
| Maximum Power Current (Imp) | A | 10.64 | 10.71 | 10.77 | 10.84 | 10.91 |
| Maximum System Voltage | V | ICE 1500VDC/UL1500(VDC) | ||||
| Maximum Series Fuse Rating | A | 20 | ||||
| ELECTRICAL DATA@NOCT | LH-435MH | LH-440MH | LH-445MH | LH-450MH | LH-455MH |
| Pmax[W] | 324.9 | 328.6 | 332.3 | 336.1 | 339.8 |
| Vmp[V] | 38.1 | 38.3 | 38.5 | 38.6 | 38.8 |
| Imp [A] | 8.53 | 8.59 | 8.64 | 8.7 | 8.75 |
| Voc[V] | 45.7 | 45.8 | 46 | 46.2 | 46.4 |
| lsc[A] | 9.21 | 9.27 | 9.33 | 9.38 | 9.43 |
| MECHANICAL SPECIFICATIONS | |
| Solar Cell Type | Mono Crystalline |
| Number of Cells | 144pcs(24x6) |
| Module Size | 2115*1052*35mm |
| Weight | 24kg |
| Glass | 3.2mm tempered glass |
| Back Sheet | White or Black |
| Frame | Anodized aluminum alloy .silver or black |
| Junction Box | IP68 |
| Quantity of Diodes | 3 pcs |
| Cable | 4.0mm2 1100mm |
| Connector | MC4 Compatible |
| Wind/Snow Load | 3600pa/5400pa |
PACKAGING CONFIGURATION
| Modules per box: | 30 pieces |
| Number per 20GP: | 275 pieces |
| Modules per 40’ HQ: | 660 pieces |
