14137A - 14276 Tapered Roller Bearing Dimension 34.925 × 69.012 × 19.845 mm
Price:
Negotiable
MOQ:
20
Delivery Time:
10-16 Working
Brand:
QRL
Product Description
14137A - 14276 Tapered Roller Bearings Dimensions: 34.925 × 69.012 × 19.845 mm
Tapered Roller Bearing Specification
Specifications
Series |
14000 |
Cone Part Number |
14137A |
Cup Part Number |
14276 |
Design Unit |
Inch |
Bearing Weight |
0.70 lb0.3 Kg |
Cage Material |
Stamped Steel |
Inch Taper Roller Bearing Description
Tapered roller bearings have specially designed raceways and asymmetrical rollers. The bearings can accommodate axial loads acting in one direction and simultaneously acting radial loads. The load is transmitted between the raceways via the rollers at an angle to the bearing axis, while the flange guides the rollers.
Product number
| Bearing | Specification | Rated Load(KN) | Speed(r/min) | Weight | ||||
| No. | d(mm) | D(mm) | W(mm) | Cr(N) | Cor(N) | Grease | Oil | kg |
| 30202 bearing | 15 | 35 | 11.75 | 15.8 | 14.4 | 22000 | 28000 | 0.053 |
| 30203 bearing | 17 | 40 | 13.25 | 21.2 | 21.3 | 19000 | 27000 | 0.075 |
| 30204 bearing | 20 | 47 | 15.25 | 28.2 | 30.6 | 22000 | 28000 | 0.126 |
| 30205 bearing | 25 | 52 | 16.25 | 29.4 | 22.54 | 20000 | 25000 | 0.157 |
| 30206 bearing | 30 | 62 | 17.25 | 45.4 | 50.5 | 18000 | 24000 | 0.231 |
| 30207 bearing | 35 | 72 | 18.25 | 56.8 | 63.5 | 20000 | 25000 | 0.331 |
| 30208 bearing | 40 | 80 | 19.75 | 63 | 74 | 17000 | 22000 | 0.422 |
| 30209 bearing | 45 | 85 | 20.75 | 71.3 | 83.8 | 16000 | 22000 | 0.474 |
| 30210 bearing | 50 | 90 | 21.75 | 73.3 | 92.1 | 17000 | 22000 | 0.53 |
| 30211 bearing | 55 | 100 | 22.75 | 94.6 | 112.8 | 15000 | 20000 | 0.712 |
| 30212 bearing | 60 | 110 | 23.75 | 103.3 | 130 | 14000 | 19000 | 0.904 |
| 30213 bearing | 65 | 120 | 24.75 | 120.6 | 152.6 | 15000 | 20000 | 1.13 |
| 30214 bearing | 70 | 125 | 26.25 | 138.3 | 173.7 | 13000 | 18000 | 1.261 |
| 30215 bearing | 75 | 130 | 27.25 | 138.4 | 185.4 | 12000 | 16000 | 1.36 |
| 30216 bearing | 80 | 140 | 28.25 | 167.7 | 212.9 | 13000 | 18000 | 1.675 |
| 30217 bearing | 85 | 150 | 30.5 | 177.6 | 236.8 | 11000 | 16000 | 2.06 |
Taper Roller Bearings Applications
- 1 These maximum fillet radii will be cleared by the bearing corners.
- 2 These maximum fillet radii will be cleared by the bearing corners.
- 3 Negative value indicates effective center inside cone backface.
- 4 Based on 90 x 106 revolutions L10 life, for The Timken Company life calculation method. C90 and Ca90 are radial and thrust values.
- 5 Based on 1 x 106 revolutions L10 life, for the ISO life calculation method.
- 6 Based on 90 x 106 revolutions L10 life, for The Timken Company life calculation method. C90 and Ca90 are radial and thrust values for a single-row, C90(2) is the two-row radial value.
- 7 These factors apply for both inch and metric calculations. Consult your Timken representative for instruction on use.
- 8 These factors apply for both inch and metric calculations. Consult your Timken representative for instruction on use.
- 9 These factors apply for both inch and metric calculations. Consult your Timken representative for instruction on use.
- 10 Geometry constant for Lubrication Life Adjustment Factor a3l.
