SMD2020 Smart LED Poster Displays P2.5 Floor Standing Indoor Retail Solution 640*1920mm
p2.5 floor standing indoor led display retail solution WIFI 4G USB led poster portable digital signage smart led iposter
Function and Technology Character Introduction:
1. P2.5 LED full color screen play freely broadcast pictures, text, VCD / DVD, 3 Dcartoon, television, video and other kinds of programming.
2. Multiform language editions, such as English, French, Germany, Greek, Russian and so on. Can be connected with PC and the website,
and also can be controlled remotely via wireless controller
3. Custom sizes can also be made Optional HD security cameras with digital ptz and offsite video storage.
4. When customers choose to adopt 3D playback mode,the video wall will display stunning HD images. Whether it is live TV, exhibition or digital advertising, it can fully perform the wonderful vision and let the audience enjoy the extraordinary visual experience
5. LED uses cold light-emitting technology, the brightness of outdoor LED display is greater than 8000mcd㎡ .
Products Applications:
Widely used in shopping malls, catering industry, product launches, weddings, hotels, airports, luxury stores, chain stores, reception halls, mobile screens, real-time video, catering industry, reception halls, product launches, mobile screens, chain stores, etc.
SPECIFICATIONS Parameters:
| Product parameter | |
| led module | |
| Pixel pitch (mm) | P2.5 |
| Pixel density (point /㎡) | 160000 |
| Module size (mm) | |
| Module resolution (WxH) | 128X64 |
| Package form | SMD2020 |
| scanning method | 1/32S |
| Refresh rate (Hz) | ≥1920/3840(Optional) |
| White balance brightness (Nits) | ＞800 |
| Color temperature (K) | 3200-9300(Adjustable ) |
| Gray scale | ≥14bit |
| Frame change frequency | 60-120Hz |
| Viewing angle (horizontal/vertical) | 160°/160° |
| Protection level (front/back) | IP31 |
| Average/peak power consumption (W/㎡) | 850/350 |
| Face mask | NO |
| cabinet | |
| cabinet size (mm) | 640X1920 |
| Screen weight (Kg) | 15 |
| cabinet module composition (WxH) | 2X12 |
| Cabinet resolution (WxH) | 256X768 |
| Flatness (mm) | ≤0.2 |
| Maintenance method | Pre-maintenance |
| cabinet material | Die-cast aluminum |
| Application Environment | |
| Input voltage (V) | 110-240 |
| Operating temperature (℃) | -20~50 |
| Working humidity (RH) | 10%-95% |
| Service life (H) | ≥100000 |
| Model type (using video processor) | AV,S-Video,VGA,DVI,HDMI,SDI,DP |
| Control distance | Category 5 network cable :＜100m,Single mode fiber :＜10km |
| certified product |  |
Weiye poster series led strip display screen advantage:
1. Under the proper current and voltage, the life of the LED can reach 100,000 hours .
2. indoor viewing angle can be greater than 160 degrees, outdoor viewing angle can be greater than 120 degrees.
3. Large-scale cluster control and management
4. Intelligent adjustment of screen brightness
5. indoor viewing angle can be greater than 160 degrees, outdoor viewing angle can be greater than 120 degrees.
