PA9T PCB Board To Board Connectors Male Female 0.5mm Btb Connector

• The main technical characteristics of the board to board connector is the board to board male and female connector pair use, and the plastic body of the connector and terminal have strict requirements, board to board connector is divided into double slot board to board, single slot board to board and side insert board to board three, commonly used spacing has 0.5mm and 0.8mm spacing, Board to board is used in connecting two PCBS or PCB and FPC to enable mechanical and electrical connections. Surface plate connector is all types of connector products, threatening the plate connector of transmission capacity is the strongest one, can be widely applied to many areas, threatening the board is mainly used in digital products/communications equipment, power systems, industrial automation, health care equipment, intelligent household equipment, military equipment and other industries.

• Board - to - board connectors can be constructed for easy machine circuit design. The insulation wall is set on the bottom of the connector, so that the PCB board wiring and metal terminal do not contact can be wiring in the bottom face of the connector, for the miniaturization of PCB board is quite beneficial; Board to board contact structure, with strong environmental resistance, not only soft, and the use of high contact reliability of the firm connection, in order to improve the group force of the socket and plug, through the fixed metal parts and contact part of the simple locking mechanism, in improving the group force at the same time, so that the lock has a sense of inserting and pulling.

• About the application of board-to-board connectors:

  In electronics manufacturing the entire device may need to fit the space available because the device may be split into two or more boards if the PCB at the board design stage tends to take up too much space. Board-to-board connectors connect power and signals from board to board to complete all connections.

  Board-to-board connectors simplify the circuit board design process. Smaller PCBS often require manufacturing equipment that cannot accommodate larger PCBS. Power consumption is considered when extruding devices into a single PCB or multiple PCBS.

  The use of board-to-board connectors also simplifies the production and testing of electronic equipment. Simplified testing in the electronics manufacturing industry reflects significant cost savings. High-density PCBS have more traces and components per unit area, and equipment or products are best designed with several interconnected MDBS rather than a single HDBS.

.

.

.

.
