3 Ton Per Hr Alfalfa Pellet Production Line 4.5mm To 8mm Small Cattle Feed Plant
3 Ton Per Hr Poultry Feed Production Line Small Animal Feed Plant
The machine sets pulverize, mix in an organic whole, have production efficiency high, take up space small, save manpower to wait for a characteristic.
The grinding process adopts the feed of elevator, which is especially suitable for the production and processing of laying hens' feed. Applicable to feed processing households and various scale of aquaculture feed processing.
feed pellet production line feed pellet plant Poultry feed pelletizer machine to make wood pellets have 2.5mm,3mm,4mm,5mm,6mm,8mm,10mm,12mm mould for your choice.
a. For pig, the pellet diameter is usually ø3.5-6.5mm.
b. For cattle, the pellet diameter is usually ø4.5-8mm.
c. For chicken, pellet diameter is usually ø3.2mm.
d. For fish, pellet diameter is usuallyø2.0, ø2.5, ø3.0mm.
e. For shrimps, pellet diameter is usually ø1.0-ø3.5mm.
Pellet length is customized.
Specifications for the palleting machine:
| Model No. | Main Power (kw) |
Feeder Power (kw) |
Adjusor power (kw) |
Capacity (Ton/hr) |
| SZLH250 | 22 | 1.5 | 2.2 | 0.6-1.0 |
| SZLH304 | 30/37 | 1.5 | 2.2 | 1-3 |
| SZLH320 | 37 | 1.5 | 2.2 | 2-4 |
| SZLH350 | 55 | 1.5 | 3 | 3-5 |
| SZLH400 | 75 | 2.2 | 3 | 8-10 |
| SZLH420 | 90 | 2.2 | 3 | 10-18 |
Flow of the machines:
1. mill and mixer 2. screw feeder 3. palleting machine 5. Cooling machine 6. Screener 7. Packing machine
Feed Granules
| Machine name | No. | Product | type | Power(KW) |
| Raw materials receiving and crushing and mixing system | 101 | Screw Conveyor | TSLL16 | 2.2 |
| 102 | Hammer Crusher | SFPZ56*20 | 15 | |
| 103 | Mixer | SHW1.0 | 7.5 | |
|
Pelleting system |
201 | Bucket Elevator | TDTG36/18 | 2.2 |
| 204 | Pellet Machine(include control box) | SZLH250 | 11*2+2.2+0.75 | |
|
Cooling system |
303 | Airlock | GFY250 | 0.75 |
| 304 | Counter Flow Cooler | SKLN11 | 0.75 | |
| 305 | Air Blower | 4-72-4A | 5.50 | |
| 308 | Pellet crusher | SSLG15*80 | 5.5 | |
| 309 | Manual Three-way | SD20*20 | ||
| Auxiliary System | 402 | Rotary Screener | SFJH80*2d | 1.5 |
| Auxiliary System | 601 | Boiler |
We provide both single equipment and complete feed making line, and accessories are also available. We can offer customized solutions for machine size ,feeder , screen , aspiration system , underneath hopper etc.
Service we provided
1. Free consultation service before, during, and after sales;
2. Free Project planning and design services upon clients' special demands;
3. Debugging and inspecting of equipment until everything is functional before leaving the factory;
4. Overseas installation and training of equipment maintenance and operating personally;
5. Provide basic production techniques and formulas;
