Machinery Packaging Machine Multi-Function Packaging Machines

Stand Up Loose Triangle Tea Bag Machine Nylon Packing 20-45 bags/min

Price Negotiable
Price: Negotiable
MOQ: Negotiable
Delivery Time: 15 - 25 / day
Brand: Shilong
Product Description



Stand up Loose Nylon Triangle Tea Bag Packing Machine Nylon Triangle





1. Description:
TEA BAGS WITH OVERWRAP
Teabags with an individual overwrap will add appeal and value to your tea line. These tea bags include both a string and a tag.
No staples are used.
Individual overwrap tea bags are more expensive to produce than the simple "pillow style" teabag.
We offer one finished size of the overwrap tea bag (70mm x 80mm).
Note: The online video of machine operation.


2. Packing materials:
Fanning tea/buckwheat tea/medicinal plants and so on.
This tea bag packing machine is a high precision automatic line used for packing broken tea and similar herbs into small bags.


3. Feature:
This automatic tea bag packing machine is our newest model, and it has features filling, heat sealing, threading, labeling, and over-wrapping functions. Meanwhile, it also has an adjustable loading system for filling different sized tea bags. Adopting sealing pads in place of the sealing rollers used in machines of previous generations, this new system greatly improves the machine's flexibility and enables the use of different packaging materials. The main materials include paper/PE, plastic/foil/PE, and plastic/PE.



Tea Bag Packing Machine Specification



Unwind quantity 1 piece
Particle content ≤ 2 ± 0.5 g / bag ( other specifications can be customized )
Packaging material requirements Inner bag: Nylon, non-woven fabric, corn fiber and other ultrasonic heat-sealable materials
Outer bag :  heat-sealable composite film
Production speed Triangle bag inner and outer bag 20-45 bags/min (specifically according to the material)
Tea bag size Inner bag : 58 * 60 (140mm) Outer bag: 80 * 90mm
Inner bag : 68 * 70 (160mm) Outer bag: 90 * 100mm
Inner bag : 80 * 80 (180mm) Outer bag: 100 * 110mm
Unwinding outer diameter ≤ Φ400㎜
Inner diameter of unwinding paper core Φ76㎜
Air pressure ≥ 0.6Mpa ( gas supply guaranteed by the customized party )
Electric power of the motor in the machine About 3.5 Kw ( 220V )
Equipment appearance About L 1800 * W 900 * H 1800 ( mm )
Equipment weight About 50kg
