40Cr Hydraulic Rock Hammer For Excavator 135mm Rod Concrete Pavement Breaker
Price:
Negotiable
MOQ:
1 set
Delivery Time:
5-15 working days
Brand:
HANYUN
Product Description
Excavator Digging Breaker Hydraulic Digger Concrete Breaker 135mm Drill Rods
(1) Main technical parameters on excavator digging breaker Hwith 135mm drill rods
| Breaker Model | HY135 |
| Breaker shell (KGS) | 600 |
| Total weight (KG) | 1663 |
| Size (MM) | 1610*530*1280 |
| Driving oil pressure (KG/CM2) | 180-220 |
| Driving oil flow (L/MIN) | 100-150 |
| Striking(BPM) | 350-600 |
| Soft hose diameter (INCH) | 1 |
| Breaker chisel diameter (MM) | 135 |
| Breaker chisel weight (KG) | 125 |
| Applicable carrier weight (T) | 18-23 |
(2) Standard details on 135mm hydraulic breaker drill rods
(Different size and types could also be customized to suit different demands)
| Breaker drill rods Model | Diameter(MM) |
Length (MM) |
Weight (KGS) |
Applicable excavator (T) |
| HYQG45 | 45 | 500 | 8 | 1.5-3 |
| HYQG53 | 53 | 600 | 12 | 3-5 |
| HYQG68 | 68 | 700 | 16 | 5-7 |
| HYQG75 | 75 | 750 | 22 | 7-9 |
| HYQG85 | 85 | 850 | 48 | 9-12 |
| HYQG100 | 100 | 1000 | 50 | 13-15 |
| HYQG120 | 120 | 1200 | 115 | 16-19 |
| HYQG135 | 135 | 1300 | 125 | 19-23 |
| HYQG140 | 140 | 1300 | 130 | 20-24 |
| HYQG150 | 150 | 1500 | 190 | 30 |
| HYQG165 | 165 | 1500 | 220 | 30-36 |
| HYQG175 | 175 | 1600 | 260 | 36-40 |
| HYQG180 | 180 | 1700 | 280 | 40 |
| HYQG185 | 185 | 1700 | 300 | 40-45 |
| HYQG190 | 190 | 1700 | 320 | 46-50 |
| HYQG195 | 195 | 1700 | 340 | 48-55 |
| HYQG200 | 200 | 1700 | 370 | 55-60 |
