High Resolution P3.91 Outdoor LED Display Screen 500x500mm LED Video Wall Panel
nationstar gold thread for stage background led display big screen
Product presentation
1.Energy-Savingand Low Power Consumption;
2.Even Current Backup for Power Supply, Never Black Screen;
3.Great Heat-Dissipation, Low Temperature Rise,Waterproof IP65;
4. Modularization Design, Easily Front and Rear Maintenance;
5.3840Hz-6420Hz High Refreshing Ratio Picture;
6.lt can be instant to be Tile Floor Screen or Magic Cube Screen;
7.Our Private Mode, Excellent Quality and Service.
| Pixel Pitch | 4.81mm | |||
| LED Lamp | SMD1921 | |||
| IC | ICN2153 | |||
| Module Size | 250x250mm | |||
| Module pixels | 52x52dots | |||
| Cabinet Size(WxHxD)(mm) | 500x1000x88 mm | |||
| Module Quantity(pcs) | 8 | |||
| Cabinet resolution WxH | 104x208dots | |||
| Cabinet Material | Aluminum die casting | |||
| Cabinet Weight (kg) | 14 | |||
| Average Power/sqm (watts) | 200 | |||
| Max Power/sqm(watts) | 650 | |||
| Brightness | 4500-5000cd/㎡ | |||
| Viewing Angle | H:160°, V:120° | |||
| Best Viewing Distance | 3.91-200 meters | |||
| Brightness Control | 256 level | |||
| Gray scale | 16bit | |||
| Refresh frequency | 3840hertz | |||
| Driving mode | 1/16 scan | |||
| Input power frequency | 50 or 60 Hertz | |||
| Input Voltage | 110 ～ 240 Volt,60Hz | |||
| Blind spot rate | ＜1/10000 | |||
| Lifetime at 50% brightness | 100000 hours | |||
| Ingress Protection | IP65 | |||
| Operating temperature | ﹣20 ～﹢60 ℃ | |||
| Operating humidity | 10％ ～ 90％ | |||
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km | |||
| Signal input format | HDMI,DVI,SDI,VGA etc. | |||
| Operating system | Windows (2000/XP/Vista/7/8/10) | |||
FAQ
Q1. What is the MOQ?
A: 1pc panel, but we suggest to get bigger video wall to check better visual experience.
Q2: Do you provide video processor?
A: Yes, we configure video processor from Novastar.
Q3: How to install the rental LED display?
A: The rental LED display is usually installed by hanging or stacking.
Q4: Can you provide installation structures?
A: Yes, we can provide hanging beams for hanging installation, or back bracket for stacking installation.
Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test for 72hrs before delivery.
Q6: How long is your warranty?
A: 2 years, we will be responsible for free repairment or replacement for defective parts.
