120x120 Dots P8 Outdoor LED Displays Board Die Casting Aluminum Back Maintenance
120x120 Dots P8 Outdoor LED Displays Board Die Casting Aluminum Back Maintenance
Die casting aluminum back maintenance P8 led board display floor mounted type
Product presentation
1. Multi-Purpose Panel for More Application Scenarios
2. Outdoor and indoor advertising, digital billboards, advertising companies sports halls, fields, playgrounds,school church,airports, bus stations and railway passenger terminals.
3. With sensitive control system, it can adjust screen brightness automatically according to the lighting change of indoor and outdoor, saving energy to reduce your operating costs greatly.
4. High refresh rate and high gray make the picture more realistic, which meets the demand of high visual quality of commercial usage.
5. It can turn on and turn off the screen by software timing or manually at any time, achieving unattended function.
6. The most advanced automated production equipment and professional team, selection of first-class raw materials, strict raw materials and process control.
7. Fanless design prevents dust and water vapor from being brought into the cabinet
8. Savings in Electricity Costs,300 Sqm, 5 years , Save $200,000 on Electricity Costs
9. With 140°-160 ° ultra-wide viewing angle, the screen can be seen from various positions.
| Pixel Pitch | 8mm | |||
| LED Lamp | SMD3535 | |||
| LED configuration | SMD 3 in 1 | |||
| Module Size | 320mm x 160mm | |||
| Module pixels | 40x20dots | |||
| Cabinet Size(WxHxD)(mm) | 960x960x108mm | |||
| Module Quantity(pcs) | 18 | |||
| Pixel Density | 120x120 dots | |||
| Cabinet pixels | 14400 dots | |||
| Cabinet Weight (kg) | 28 | |||
| Average Power/sqm (watts) | 200 | |||
| Max Power/sqm(watts) | 600 | |||
| Brightness Control | 256 level | |||
| Gray scale | 14 bit | |||
| Refresh frequency | 1920hertz | |||
| Driving mode | 1/5 scan | |||
| Input power frequency | 50 or 60 Hertz | |||
| Input Voltage | 110 ～ 240 Volt,60Hz | |||
| Blind spot rate | ＜1/10000 | |||
| Lifetime at 50% brightness | 100000 hours | |||
| Ingress Protection | IP65 | |||
| Operating temperature | ﹣20 ～﹢60 ℃ | |||
| Operating humidity | 10％ ～ 90％ | |||
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km | |||
| Signal input format | HDMI,DVI,SDI,VGA etc. | |||
| Operating system | Windows (2000/XP/Vista/7/8/10) | |||
