Wall Mounted Type P10 Led Display Screen For Advertising Outdoor SMD3535
Wall Mounted Type P10 Led Display Screen For Advertising Outdoor SMD3535
Basketball Court Wall Mounted Type P10 Led Display Digital Billboard
Product presentation
1. The cabinet body is processed by CNC, with only ±0.1mm tolerance, and 3 times precision that of the iron/steel cabinet body.
2. Outdoor and indoor advertising, digital billboards, advertising companies.
3. With sensitive control system, it can adjust screen brightness automatically according to the lighting change of indoor and outdoor, saving energy to reduce your operating costs greatly.
4. High refresh rate and high gray make the picture more realistic, which meets the demand of high visual quality of commercial usage.
5. The advertising contents can be changed at any time, for different customers and various advertisements.
6. Savings in Electricity Costs,300 Sqm, 5 years , Save $200,000 on Electricity Costs.
7. Fanless design prevents dust and water vapor from being brought into the cabinet.
| Pixel Pitch | 10mm | |||
| LED Lamp | SMD3535 | |||
| LED configuration | SMD 3 in 1 | |||
| Module Size | 320mm x 160mm | |||
| Module pixels | 32x16dots | |||
| Cabinet Size(WxHxD)(mm) | 960x960x108mm | |||
| Module Quantity(pcs) | 18 | |||
| Cabinet resolution WxH | 96x96dots | |||
| Cabinet Material | magnesium alloy | |||
| Cabinet Weight (kg) | 29 | |||
| Average Power/sqm (watts) | 240 | |||
| Max Power/sqm(watts) | 800 | |||
| Brightness | 6500cd/㎡ | |||
| Viewing Angle | H:160°, V:120° | |||
| Best Viewing Distance | 10-200 meters | |||
| Brightness Control | 256 level | |||
| Gray scale | 14 bit | |||
| Refresh frequency | 1920hertz | |||
| Driving mode | 1/2 scan | |||
| Input power frequency | 50 or 60 Hertz | |||
| Input Voltage | Input Voltage | |||
| Blind spot rate | ＜1/10000 | |||
| Lifetime at 50% brightness | 100000 hours | |||
| Ingress Protection | IP65 | |||
| Operating temperature | ﹣20 ～﹢60 ℃ | |||
| Operating humidity | 10％ ～ 90％ | |||
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km | |||
| Signal input format | HDMI,DVI,SDI,VGA etc. | |||
| Operating system | Windows (2000/XP/Vista/7/8/10) | |||
One- Stop Solution Service
1.3D/CAD engineering drawing to confirm project execution/implementation as presale service within 72 hours.
2.Free CAD drawings for steel structure, signal/power connections of led display which guide for site cable arrangement and structure preparation in advance.
3.7/24 online remote control service , and local engineer service within 8 hours contact.
4.Free technical training in factory.
5.MPLED engineers will fly to the site if you need local service.
6.Expanding market plan with professional MPLED team over 8 years experience.
7.Multiple options for global transportation, like FOB, CIF, DDP, DDU to most countries.
Product Solution
1. Mature customized solution team with engineers support.
2. Serious material and procedure QC such as 72 hours working test, shock proof test, waterproof test, material checkout, damp proof package, etc.
3. Product updates each quarter to do improvement and innovations to help our clients win more projects in their market.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
