Indoor SMD P3 LED Screen 500*1000mm Stage Rental LED Screen Panels
Indoor SMD P3 LED Screen 500*1000mm Stage Rental LED Screen Panels
product presentation
1. 500*500mm and 500*1000mm standard cabinet size Ultra-Light die-casting aluminum. ultra-thin thickness with 80mm.For easy transport and Portable.
2. The curve version (can be adjusted between -5° and +10°) and 90° splicing version are provided to help customers easily realize their unlimited creativity.
3. Lightweight,Panel weight only 14Kg ,More than 20% Lighter than regular products.
4. Provide various frame structure options.No need for wind bracing, and the wind resistance level can satisfy the needs of outdoor use.
5. Convenient Installation And Maintenance By Magnetic Module Design.
6. No Delay From End-To-End.
| Pixel Pitch | 3.91mm | |||
| LED Lamp | SMD2121 | |||
| IC | ICN2153 | |||
| Module Size | 250x250mm | |||
| Module pixels | 64x64 dots | |||
| Cabinet Size(WxHxD)(mm) | 500x1000x88 mm | |||
| Module Quantity(pcs) | 8 | |||
| Cabinet resolution WxH | 128x256dots | |||
| Cabinet Material | Aluminum die casting | |||
| Cabinet Weight (kg) | 14 | |||
| Average Power/sqm (watts) | 200 | |||
| Max Power/sqm(watts) | 650 | |||
| Brightness | 1200cd/㎡ | |||
| Viewing Angle | H:160°, V:120° | |||
| Best Viewing Distance | 3.91-200 meters | |||
| Brightness Control | 256 level | |||
| Gray scale | 16 bit | |||
| Refresh frequency | 1920hertz | |||
| Driving mode | 1/16 scan | |||
| Input power frequency | 50 or 60 Hertz | |||
| Input Voltage | 110 ～ 240 Volt,60Hz | |||
| Blind spot rate | ＜1/10000 | |||
| Lifetime at 50% brightness | 100000 hours | |||
| Ingress Protection | IP30 | |||
| Operating temperature | ﹣20 ～﹢60 ℃ | |||
| Operating humidity | 10％ ～ 90％ | |||
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km | |||
| Signal input format | HDMI,DVI,SDI,VGA etc. | |||
| Operating system | Windows (2000/XP/Vista/7/8/10) | |||
FAQ
Q: Are you manufacturer or trade company?
A: We are manufacturer,
Q: Do you offer OEM&ODM service?
A: Yes, we do.
Q: What’s the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS certification.
Q: Which place will use ITC equipment?
A: Our products are widely used in International Conferences, Governments,Banks,Churches, Highways,Airports,Parliaments,Education institutes,Hotel,Private corporate conference hall and so on.
