Front Rear Module Rental LED Displays Maintenance 8x12 Screen Solutions
Front Rear Module Maintenance 8x12 Led Display Solutions 8x12 Led Display Solutions
product presentation
1. 500*500mm and 500*1000mm standard cabinet size Ultra-Light die-casting aluminum. ultra-thin thickness with 80mm.For easy transport and Portable.
2. New design without fans, no noise and lower consumption with handlebar. We can print your logo or company name on our cabinet and flight case for free.
3. Super slim and light, easy to carry and transport;
4. Low brightness and Hight gray scale:14Bit-16Bit gray scale to bring perfect display performance with no shadows.
5. Each individual module stores its calibration and operating parameters. Equipped with identical push-out modules, maintenance is a breeze.
6. Due to its stacking, hanging and curved installation options, the Black Pearl LED panels offer flexible solutions for both rental and fixed installation applications. Through concave or convex curving a large field of view and a more immersive experience can be created.
| Pixel Pitch | 3.91mm | |||
| LED Lamp | SMD2121 | |||
| IC | ICN2153 | |||
| Module Size | 250x250mm | |||
| Module pixels | 64x64 dots | |||
| Cabinet Size(WxHxD)(mm) | 500x1000x88 mm | |||
| Module Quantity(pcs) | 8 | |||
| Cabinet resolution WxH | 128x256dots | |||
| Cabinet Material | Aluminum die casting | |||
| Cabinet Weight (kg) | 14 | |||
| Average Power/sqm (watts) | 200 | |||
| Max Power/sqm(watts) | 650 | |||
| Brightness | 1200cd/㎡ | |||
| Viewing Angle | H:160°, V:120° | |||
| Best Viewing Distance | 3.91-200 meters | |||
| Brightness Control | 256 level | |||
| Gray scale | 16 bit | |||
| Refresh frequency | 1920hertz | |||
| Driving mode | 1/16 scan | |||
| Input power frequency | 50 or 60 Hertz | |||
| Input Voltage | 110 ～ 240 Volt,60Hz | |||
| Blind spot rate | ＜1/10000 | |||
| Lifetime at 50% brightness | 100000 hours | |||
| Ingress Protection | IP30 | |||
| Operating temperature | ﹣20 ～﹢60 ℃ | |||
| Operating humidity | 10％ ～ 90％ | |||
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km | |||
| Signal input format | HDMI,DVI,SDI,VGA etc. | |||
| Operating system | Windows (2000/XP/Vista/7/8/10) | |||
FAQ
Q: Are you manufacturer or trade company?
A: We are manufacturer,
Q: Do you offer OEM&ODM service?
A: Yes, we do.
Q: What’s the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS certification.
Q: Which place will use ITC equipment?
A: Our products are widely used in International Conferences, Governments,Banks,Churches, Highways,Airports,Parliaments,Education institutes,Hotel,Private corporate conference hall and so on.
