3.55V-3.70V Polymer Lithium Ion Battery Pack 7100mAh For Safety Equipment Voltage
Product Description:
Worldwide approvals and certification of safety standards
No development costs, fast time-to-market
Life expectancy: Up to 80% of initial capacity after 300 cycles
Smart batteries with numerous features according to the SMBus specification
Rechargeable batteries have built-in high quality PCB board,
thermal protectors and circuit breakers,
effectively avoiding the over-charge, and short circuit.
High Capacity with Small Size
Product Parameters:
| Item | Specification |
| Pack Configuration: | 1 Series 2Parallel (1S2P) |
| Standard Environmental Test Conditions: | |
| 1): Unless otherwise specified, all tests stated in this Product Specification are conducted at below conditions: | |
| Temperature: 25 3°C (“Temperature Condition”) | |
| Humidity: 65 20% RH (“Humidity Condition”) | |
| 2): Numeric criteria annotated by “*” means such criteria are only applicable to fresh unused Product within 30 days from manufacture . Products either have been used or stored for a period longer than 30 days by Customer and/or its customer may exhibit an inferior numeric parameter than such criteria. Customer agrees that such occurrence does not constitute non-conformance of specification. | |
| Minimal Capacity(Cmin) | 6840mAh(1S2P) |
| Typical Capacity | 7100mAh(1S2P) |
| *Typical Voltage | 3.85V |
| Charge Cut-off Voltage | 4.35±0.03V |
| Discharge Cut-off Voltage | 3.0V |
| Charge current | 0℃to 15℃ |
| 15℃to 45℃ | |
| 45℃to 60℃ | |
| Discharge current | Standard:0.2C |
| Maximum:2A | |
| Storage Temperature | -20°C to 45°C |
| -20°C to 35°C | |
| -20°C to 25°C | |
| Initial Resistance | ≤ 180mΩ (Estimated) |
| Allowable Humidity Range | 65 ± 20% RH |
| Pack Voltage(as of shipment, alternative) | 3.55V~3.70V |
| 3. 8V ~ 4.0V | |
| size | 62*84*8.97*39.6mm |
Main Applications
Mainly used for security equipment, Network signal tester.
Main Functions
Lithium Polymer batteries make it possible for small objects to achieve intelligence. Bendable Lithium Polymer cells
open up new applications for lithium-ion batteries. For small, thin and flexible devices such as smart cards, trackers
and smart wearables, Lithium Polymer battery can provide a certain amount of electric energy to drive their functions
of signal transmission or data acquisition. And Lithium Polymer secondary battery allows charging and discharging
cycle, broadening the servicing life of electronics products.
