P950 Process Purity Oxygen Analyzer

P950 purity oxygen analyzer is with ion current principle, which is capable of oxygen purity measurement range 10-96%.

Features

• 240×128 LCD display oxygen concentration and other settings;
• Isolated 4-20mA signal output, with 0-1V and 0-10V as options;
• Easy to replace sensor;
• Standard RS232 two-way communication port;
• Two way SPST alarms;
• Automatic data storage in a certain interval time, and browsing data at any time

Technical Specifications

Range: 10.00~96.00% O2·

Accuracy: ±2% FS

Repeatability: ±1% FS

Stability: ±1% FS/7d

Response Time: T90＜60S

Power Supply: 220V AC, 50/60Hz·

Consumption: Less than 10VA·

Contact Point Capacity:24V DC, 0.2A

Analog output: 4-20mA (Allow less than 500Ω load)

Install conditions: Plate mounting, non explosion area·

Ambient Temperature: 0℃ to 45℃, non-condensing·

Ambient Humidity: Less than 80%

·Storage Temperature: -5℃ to 50℃

·Gas flow:400 ~ 600ml/min, gas pressure: 86 ~ 106kPa

Equipment Index:

·Display window: 4 digital pipes

·Sensor: Ion flow oxygen sensor

·Sensor Life: More than 2 years (normal use)

·Analyzer Life: More than 5 years (normal use)

Applications

Air separation, PSA oxygen generator, Medical oxygen, Petro-chemical, and other oxygen purity detection in inert gas mixtures.

Order knowledge

Measure range

Sample gas pressure

Sample gas composition
