TBB KINERGIER PRO CK 5.0M Inverter Paralleled To 72KW Three Phase

TBB KINERGIER PRO CK 5.0M 5.0M Inverter Paralleled to 24KW single phase 72KW three phase

Kinergier Pro is a new generation inverter charger, combined with an inverter, battery charger, and transfer switch into one compact package, allowed to expand its system capacity through parallel and three phase operation up to 9 units. Featuring Oms UPS transfer time, it is an ideal inverter for powering various mission-critical loads. It is designed for various types of off grid systems including DC Coupled PV system, AC Coupled PV system, or even a combination of both, to maximize the use of PV energy.Its high surge capability makes it capable to deal with the initial currents of the high-demanding appliances, such as air conditioner, water pump, washing machine, freezer etc. Thanks to its power assist and power control function, it works well with the majority of poor generators. Kinergier Pro can automatically adjust its charging current by taking loads into account to protect the generator from overload. Once the temporary peak power appears, it can also discharge the battery to supply power to compensate the insufficient part of the generator.

Support AC Coupled system, DC Coupling system and the combination of both

High surge capacity for starting up mostly demanding appliances

Power assist function enables limited AC to power heavy loads

Ultra-fast 0-2ms transfer time to protect mission-critical loads like server and ATM

Outstanding overload capability for powering various inductive loads

Controlled by digital signal processors

Support parallel and three phase operation up to 9 units

Compatible with mainstream lithium battery brands

AGS function to automatically start and stop the generator
