24kwh BMS Power Household Solar System For Home 480Ah
Solar Off Grid Systems Energy Storage System 24kwh A Set For Home Use
Home photovoltaic energy power system is mainly applicable to the cases of insufficient power supply,time-of-use electricity, no electricity area and so on.
- In the case of insufficient power supply, the photovoltaic energy storage system can store electricity through photovoltaic power generation, and then provide backup power for the household load.
- In time-of-use area, the system can store the surplus electricity generated by photovoltaic equipment and use it during the period of when the price of electricity is high, thus reducing electricity cost.
- In areas without electricity, it can serve as an independent off-grid system together for the household load to solve the problems of no electricity supply.
|
Solar panel : JT400w-24M |
|
|
Pmax |
400w |
|
Vmp |
38.23V |
|
Imp |
8.65A |
|
Size |
1950x990x40mm |
|
Weight |
22.86Kg |
|
Cell Type |
Mono 156mm x 156mm |
|
Cell Arrangement |
72 cell in series |
|
Battery : Powerporter 24kwh |
|
|
Nominal Energy |
24.0Kwh |
|
Nominal Voltage |
51.2V |
|
Capacity |
480Ah |
|
Size |
1246x748x250 mm |
|
Weight |
230Kg |
|
Battery cell |
Lithium ion battery cell (CATL ) |
|
Cycle life |
6000+ (Promise) |
|
Installation |
Wall or floor mount |
|
Inverter : Growatt 5000TL HVM |
|
|
Battery voltage |
48 VDC |
|
Rated power |
5000W |
|
Output voltage range |
230VAC±5%@50/60Hz |
|
Mppt voltage range |
30VDC~80VDC 60VDC~115VDC |
|
Size |
130 x 350 x 455 mm |
|
Weight |
14.5kg |
|
Combiner box |
|
|
PV Fuse |
|
|
PV Cirrcuit Breaker |
|
|
PV SPD |
Surge Protective Device |
|
Genset output |
|
|
AC SPD |
|
|
ATS |
Automatic Transfer Switch |
|
RCBO |
Residual current circuit breaker with over current protection |
|
Inverter Output |
|
|
PV component |
|
|
Kabel DC & MC4 Konektor |
|
|
PV Cirrcuit Breaker |
|
|
Palang Bagian |
4mm2-6mm2-Opsional |
|
Nilai Tegangan |
600VDC(UL)/1000VDC(TUV) |
|
PV Shelf Material |
Al 6005-T5 |
| ESS-BT24-PV5-INV5 | ESS-BT24-PV10-INV10 | ESS-BT24-PV15-INV15 | |
|
Battery: powerporter 12kwh |
2 unit 12kwh / 48V / 480ah |
2 unit 12kwh / 48V / 480ah |
2 unit 12kwh / 48V / 480ah |
|
Solar panel: JT330w-24M |
12pcs (5kw) 400w/pcs |
24 pcs (10kw) 400w/pcs |
36 pcs (15kw) 400w/pcs |
|
Inverter: Growatt 5000TL |
1 unit Growatt 5000TL-HVM |
2 unit Growatt 5000TL-HVM |
3 unit Growatt 5000TL-HVM |
| System max. AC output power | 5kw | 10kw | 15kw |
| Combiner box | 1 set | 1 set | 1 set |
| Kabel DC 4mm2 | 200 meters | 200 meters | 200 meters |
| PV component | 1 set | 1 set | 1 set |
| Contact customer service and support customization | |||
