250X PA PP Tower Structured Packing
Plastic Corrugated Packing Low Liquid Loads 250X Plastic Structured Packing
Plastic perforated plate packing has similar structure with metal structured packing, which can be divided into plate packings and wire gauze packings.
The materials used for the filler are polypropylene, polyethylene, polyvinyl chloride and reinforced polypropylene.
The surface of the packing is pressed with a special stripe, and the selection of the packing is based on the operating conditions. The corrugated plate is an improved corrugated plate. The corrugated plate shall be installed vertically parallel to the longitudinal axis of the container. The corrugated direction on the plate is 30°-60° with the length direction of the plate. The ripples on the same corrugated plate are parallel to each other; The corrugations of the adjacent plates form an intersection.
When the fluid flows in this part, it moves up and down, which helps to coalesce, float up or settle the dispersed phase droplets, and greatly improves the processing capacity and separation efficiency. Plastic perforated plate packing is mainly used in oil and water separation process in oil fields and refineries.
Specification
| Performace/Material | PE | PP | RPP | PVC | CPVC | PVDF |
| Density(g/cm3)after injection molding | 0.98 | 0.96 | 1.2 | 1.7 | 1.8 | 1.9 |
| Operation TEMP.(℃) | 90 | >100 | >120 | >60 | >90 | >150 |
| Chemical Corrosion Resistance | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
| Compression Strength(Mpa) | >6.0 | >6.0 | >6.0 | >6.0 | >6.0 | >6.0 |
| Packing type | Theoretical Plate Number(piece/m) |
Surface area (m²/m³) |
Void Volume (m³) |
Bulk Density (kg/m³) |
Liquid Loading(m³/m²·h |
| 125Y | 1-2 | 125 | 0.985 | 37.5 | 0.2-100 |
| 250Y | 2-2.5 | 250 | 0.97 | 75 | 0.2-100 |
| 350Y | 3.5-4 | 350 | 0.95 | 105 | 0.2-100 |
| 500Y | 4-4.5 | 500 | 0.93 | 150 | 0.2-100 |
| 125X | 0.8-1.9 | 125 | 0.985 | 37.5 | 0.2-100 |
| 250X | 1.5-2 | 250 | 0.97 | 75 | 0.2-100 |
| 350X | 2.3-2.8 | 350 | 0.958 | 105 | 0.2-100 |
| 500X | 2.8-3.2 | 500 | 0.93 | 150 | 0.2-100 |
Applications
Air separation plant direct contact cooler.
Flue gas cooler.
Seawater scrubber.
HCl absorber.
SO2 absorber.
ClO/ClO2 scrubber.
Deaerators.
Package and Delivery
Our Company
For over 17 years, Boegger has been providing filtration solutions to a wide range of filtering industries where perfume, essence, oil, etc. Our Major products include grid structured packing, wire gauze structured packing, perforated plate corrugated packing and plate net corrugated packing, etc.To meet different filtration requirements, we deal with a variety of raw materials, steel, stainless steel, non-ferrous metals and special materials.
For special using, we also handle custom fabricated needs.Our well-trained staff have an extensive knowledge of the filtering industry and are always willing to assist with our customer’s needs.
