Screw Press Flocculation And Sedimentation

Price Negotiable

Price: To Be Negotiated

MOQ: 1 unit

Delivery Time: 30-45 days

Brand: Biocell

Product Description

Flocculation And Sedimentation Sludge Dewatering Screw Press Dehydrator Equipment

Magnetic flocculation sedimentation technology

The magnetic flocculation sedimentation technology is to add magnetic powder synchronously in the coagulation sedimentation process to make it and the pollutants flocculated into one body to strengthen the effect of coagulation and flocculation, so that the density of the generated flocs is higher and stronger, so as to achieve high-speed sedimentation. Purpose. Magnetic powder can be recycled through magnetic drum recycling. Magnetic flocculation sedimentation technology consists of reaction system, clarification system, sludge discharge system, dosing system, magnetic seed recovery system and sludge dewatering system.

Parameters

Model	DS Standard Capacity(kg/h)		Sludge Treatment Capacity(m³/h)
Model	Low Concentration	High Concentration	2000mg/L	4000mg/L	10000mg/L	20000mg/L	25000mg/L	50000mg/L
MDS101	3	6	1.5	0.75	0.6	0.3	0.24	0.12
MDS131	6	12	3	1.5	1.2	0.6	0.48	0.24
MDS132	12	24	6	3	2.4	1.2	0.96	0.48
MDS201	12	20	6	3	2	1	0.8	0.4
MDS202	24	40	12	6	4	2	1.6	0.8
MDS301	30	60	15	7.5	6	3	2.4	1.2
MDS302	60	120	30	15	12	6	4.8	2.4
MDS303	90	180	45	22.5	18	9	7.2	3.6
MDS351	60	120	30	15	12	6	4.8	2.4
MDS352	120	240	60	30	24	12	9.6	4.8
MDS353	180	360	90	45	36	18	14.4	7.2
MDS354	240	480	120	60	48	24	19.2	9.6
MDS401	100	170	50	25	17	8.5	6.8	3.4
MDS402	200	340	100	50	34	17	13.6	6.8
MDS403	300	510	150	75	51	25.5	20.4	10.2
MDS404	400	680	200	100	68	34	27.2	13.6

The residence time of the whole process is very short, so for most pollutants including TP, the probability of anti-dissolution process is very small. In addition, the magnetic powder and flocculant added in the system are harmful to bacteria, viruses, oil and various tiny particles. All have good adsorption, so the removal effect of this type of pollutants is better than the traditional process. At the same time, due to its high-speed precipitation performance, it has many advantages such as high speed, high efficiency, small footprint, and low investment compared with traditional methods.
