Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16
Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16
Product Details
The hydraulic pump of an excavator is the core component of the hydraulic system of an excavator. The hydraulic pump converts the mechanical energy of the engine into hydraulic energy for transmission, and then converts it back into mechanical energy through hydraulic motors and hydraulic cylinders.
| Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16 | |||
|
Product Name:
|
K3V Hydraulic Main Pump
|
Model Number:
|
K3V180DT-1H2R-9N16
|
| Brand Name: | Kawasaki KPM | Place Of Origin: | Japan |
|
Condition:
|
Genuine Original New
|
Delivery:
|
Within 1-3 days after payment
|
|
Inventory:
|
In stock
|
Material: | Casting Iron & Steel |
|
Packing:
|
Wooden Case
|
Payment Term:
|
T/T, Western Union, Paypal
|
| Application: | Kato Excavator | Application model: | HD1880-7 |
| Weight: | 190KGS | Dimension(L*W*H): | 98*450*63cm |
| Warranty: | 6 months | After Warranty Service: | Online support |
|
Guarantee: We will check the pumps and send detail pictures to buyer to confirm before shipping.
|
|||
K3V180DT Hydraulic Pump Spare Parts
We Provide New Kawasaki K3V280DTH Piston Pump Rotary Group, Replacement And Spare Parts, 100% Compatible With Original Kawasaki, Good Quality Piston Pump Parts And More Cost Effective Price. Spare parts include: Rotary Group, Drive Shaft, Support, Swash Plate, Yoke, Thrust Plate, Shoe Plate, Retainer Plate, Set Plate, Ball Guide, Piston Shoe, Pistons, Cylinder Block, Barrel, Valve Plate, Port Plate and other parts. Yunki is your aftermarket solutions partner for Kawasaki replacement piston pump parts. Precision piston pump parts can totally interchange with original Kawasaki, same specification and duration.
| Item No. | Name & Description | QTY (pcs) | Remark |
| 1 | K3V180DT DRIVE SHAFT | 1 | SHAFT |
| 2 | K3V180DT SUPPORT | 1 | |
| 3 | K3V180DT SWASH PLATE | 1 | YOKE |
| 4 | K3V180DT THRUST PLATE | 1 | SHOE PLATE |
| 5 | K3V180DT RETAINER PLATE | 1 | SET PLATE |
| 6 | K3V180DT BALL GUIDE | 1 | |
| 7 | K3V180DT COIL SPRING | 1 | |
| 8 | K3V180DT PISTON SHOE | 9 | PISTONS |
| 9 | K3V180DT WASHER | 1 | |
| 10 | K3V180DT CYLINDER BLOCK | 1 | BARREL |
| 11 | K3V180DT VALVE PLATE | 1 | PORT PLATE |
Features
1. With new technology the K3V series has realized higher power density.
2. K3V series can cope with enlargement of displacement despite the same installation dimensions and regulator variations as K3V’s.
3. K3V series pumps have realized higher reliability and long life so as to meet requirement of larger torque.
| Model | K3V63 | K3V112 | K3V140 | K3V180 | K3V280 | |
| Displacement /cm3 | 63 | 112 | 140 | 180 | 280 | |
| Pressure MPa
(kgf/cm2)
|
Rated | 34.3 (350) | ||||
| Peak | 39.2 (400) | |||||
| Speed
/min-1
|
Max.for self priming | 2,650 | 2,360 | 2,150 | 1,950 | 1,600 |
| Max | 3,250 | 2,700 | 2,500 | 2,300 | 2,300 | |
ADVANTAGES
1. Long life.
2. High strength.
3. Easier for maintenance
4. More accurate.
5. Anti-corrosion.
6. Suitable for various environments.
Excavator Hydraulic Pump/Swing Motor/Travel Motor Models
K5V Hydraulic pump: K5V63/ K5V70DTP, K5V112DTP, K5V140DTP
MX Hydraulic motor: MX50, MX80, MX150, MX173, MX200, MX250, MX300, MX450, MX500,MX530, MX750
M2X Hydraulic motor: M2X55, M2X63, M2X96, M2X96, M2X120, M2X128, M2X146, M2X150,M2X210
M5X Hydraulic motor: M5X130, M5X160, M5X180
DNB Hydraulic travel motor: DNB50,DNB50B, DNB50V,DNB60B
HPV Hydraulic pump: HPV125B, HPV125A, HPVO55, HPVO102, HPVO91DW, HPVO91EW, HPV116C/D/F, HPV145, HPV145D, HPV145F
MAG Hydraulic Travel motor: MAG18, MAG26, MAG33, MAG44, MAG180, MAG150, MAG170, MAG85
We offer wide range of hydraulic pumps that can suit to excavator such as Komatsu, Caterpillar, Hitachi, Kobelco, Mitsubishi, Hyundai, Volvo.
All of our Hydraulic Pumps are packed well in wooden case.
