80 #carbon seamless galvanized steel pipe
P235gh Round Galvanized Steel Pipes
Hot dip galvanized steel pipe with pickling, first to remove iron oxide on the surface of the steel tube, after acid cleaning, by ammonium chloride or zinc chloride or ammonium chloride and zinc chloride mixed aqueous solution tank cleaning, and then sent to the hot dip plating tank. Hot dipped galvanized zinc layer thickness, coating uniformity, strong adhesion, long service life, etc. Steel substrate with molten electrolyte solution in complex physical and chemical reaction, the formation of corrosion resistance of the structure compact zinc alloy layer. Pure zinc layer, alloy layer and steel substrate fused together .So the corrosion resistant ability.
| product name | P235gh Galvanized Seamless Carbon Steel Pipe |
| Material | Carbon Steel/Alloy Steel |
| Section Shape | Round |
| Grade | Q235, 20#, 201, 304, 316 ect. |
| Standard | DIN1626, DIN2391, EN10305-1, GB/T3639, ASTM/ASME A312/SA312, ASTM/ASME A269/SA269, ASTM/ASME A249/SA249, DIN 17458-85, DIN 17456-85, JIS G 3459, JIS G 3463, JIS G 3448, JIS G 3446 ect. |
| Technique | Cold Rolled, Hot Rolled, Cold Drawn |
| Package | Wrap in bundles with plastic woven bags |
| Supply Capacity | 15000 MT/Year |
| Certification | ISO9001, SGS, HSL, BV |
| Application | automobiles, motorcycles, gas springs, office chairs, construction machinery and refrigeration industry. |
| Pipe Specification (MM) | |||
| Nominal (DN) | Ⅰ External Dia. | Ⅱ External Dia. | Thickness(±10% tolerance) |
| DN 15 | 16.00 | 15.88 | 0.80 |
| DN 20 | 20.00 | 22.22 | 1.00 |
| DN 25 | 25.40 | 28.58 | 1.00 |
| DN 32 | 32.00 | 34.00 | 1.20 |
| DN 40 | 40.00 | 42.70 | 1.20 |
| DN 50 | 50.80 | 48.60 | 1.20 |
| DN 65 | 76.10 | 76.10 | 2.00 |
| DN 80 | 88.90 | 88.90 | 2.00 |
| DN 100 | 101.60 | 108.00 | 2.00 |
| DN 125 | 133.00 | 133.00 | 2.50 |
| DN 150 | 159.00 | 159.00 | 3.00 |
| DN 200 | 219.00 | 219.00 | 3.50 |
| ...... | ...... | ...... | ...... |
| Mechanical Properties | |||
| NO. | Grade |
Degree of tension / Mpa |
Elongation after break / % |
| 1 | 304 | ≥520 | ≥35 |
| 2 | 304L | ≥450 | |
| 3 | 316 | ≥520 | |
| 4 | 316L | ≥450 | |
