Lightweight Oilproof Hexagonal Gabion Mesh , Hot Dipped Galvanised Hexagonal Netting
Gabion Hexagonal Wire Mesh Basket For Control And Guide Of Water Or Flood
Stone cage net introduction:
1. Gabion is made of steel mesh with the type 80*100mm, 60*80mm, 70*90mm or 100*120mm ....mesh
2. The diameter of the wire mesh can be produced according to customer's requirment.
3. The gabion element is in the shape of block or regular cube size. These special wire bins are made of robust wire, filled with the vibrations at the quarry and transport are accompanied by the lifting straps.
4. Wires of gabion basket can be classified into mesh wire, selvedge wire and tie wire. The selvedge wire is thicker than the other two wires.
Product Description:
Heavy Zinc Coated Gabion Box Double Twist Hexagonal Woven Wire Mesh
Material: Hot dip galvanizedwire, PVC coated wire, Galfan-coated wire
Surface treatment: Hot dipped galvanized, electric galvanized and pvc coated.
Weaving character: Normal twisted, reverse twisted and double-way twisted.
Mesh Hole: 60x80mm, 80x100mm, 100x120mm
Wire Dia: 2.7mm, 3.4mm
Application:
1. Control and guide of water or flood
2. Prevent of rock breaking
3. Protect rock fall
4. Protect Water and soil protection
5. Protect bridge
6. Strengthen structure of soil
7. Protect engineering of seaside area.
8. Build Port project
9. Keep off dust wall
10. Protect roadway
Specification
| Mesh (mm) |
Wire Dia (mm) |
Wire Dia(PVC Coated) Inner/outside (mm) |
Strands |
| 60x80 | 2.0-2.8 | 2.0/3.0-2.5/3.5 | 3 |
| 80x100 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | 3 |
| 80x120 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | 3 |
| 100x120 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | 3 |
| 100x150 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | 3 |
| 120x150 | 2.0-4.0 | 2.0/3.0-3.0/4.0 | 3 |
| Length (m) |
Width (m) |
Height (m) |
Diaphragm | Volume (m3) |
Tolerance |
| 2.0 | 1.0 | 0.3 | 1 | 0.6 | L:+/-3% W:+/-5% H:+/-5% |
| 3.0 | 1.0 | 0.3 | 2 | 0.9 | |
| 4.0 | 1.0 | 0.3 | 3 | 1.2 | |
| 2.0 | 1.0 | 0.5 | 1 | 1.0 | |
| 3.0 | 1.0 | 0.5 | 2 | 1.5 | |
| 4.0 | 1.0 | 0.5 | 3 | 2.0 | |
| 1.0 | 1.0 | 0.5 | 0 | 0.5 | |
| 1.0 | 1.0 | 1.0 | 0 | 1.0 | |
| 2.0 | 1.0 | 1.0 | 1 | 2.0 | |
| 3.0 | 1.0 | 1.0 | 2 | 3.0 | |
| 4.0 | 1.0 | 1.0 | 3 | 4.0 |
FAQ:
Q:Are you a real factory?
A:yes,Hebei Hengtuo machinery Equipment Co.,LTD not only produces all kinds of stone cage machine,and the production of stone cage net,from the sources for customers to control the quality.
Q:Does your factory has export rights?
A:YES.We have more than 30 year's export experience.Your customer clearance is no problem.
Q:May I visit your factory?
A:YES,You are very welcome to visit our factory and give us your valuable advice,
