Hot Dipped Galvanized Hexagonal Wire Mesh Netting Anti Corrosion Multipurpose
80 mm , Gabion Cage Hexagonal Wire Mesh
Application:
Control and guide of water or flood, Spillway dam or diversion dam, Preventing of rockfall, Preventing soil erosion, Bridge protection, Strengthening structure of soil, Protection engineering of seaside area.
Note: special specifications can be customized processing, but also according to the customer incoming sample custom
Product Description:
Heavy Zinc Coated Gabion Box Double Twist Hexagonal Woven Wire Mesh
Material: Hot dip galvanizedwire, PVC coated wire, Galfan-coated wire
Surface treatment: Hot dipped galvanized, electric galvanized and pvc coated.
Weaving character: Normal twisted, reverse twisted and double-way twisted.
Mesh Hole: 60x80mm, 80x100mm, 100x120mm
Wire Dia: 2.7mm, 3.4mm
Specification of gabion wire mesh:
| Product name | Galvanized wire netting/chicken fence |
| Surface Treatment | Hot dipped galvanized (before/after) /Electro galvanized |
| Material | Q195 low carbon steel |
| Twist type | Reverse twist/Normal twist |
| Tensile strength | Soft 380-480MPA, HT 1100-1300MPA |
| Wire diameter | 1.2mm-5.0mm |
| Hole size | 1"- 3"(25mm - 75mm) |
| Width | 3' - 7' |
| Length | 50'/100' |
| Zinc coating | Min.60gsm - hot dipped galvanized 10-15gsm - electro galvanized |
| Usage | Mesh fence/Gabion basket |
| Standard | GB/T343, ASTM A370 |
| Original | Tianjin, China |
| Packing Way | Export waterproof package. |
FAQ:
Q:Are you a real factory?
A:yes,Hebei Hengtuo machinery Equipment Co.,LTD not only produces all kinds of stone cage machine,and the production of stone cage net,from the sources for customers to control the quality.
Q:Does your factory has export rights?
A:YES.We have more than 30 year's export experience.Your customer clearance is no problem.
Q:May I visit your factory?
A:YES,You are very welcome to visit our factory and give us your valuable advice,
