Bto-22 Razor Blade Wire Making Machine Automatic
Automatic razor barbed wire making machine
Razor barbed wire machine mainly consists of punching machine and coil machine.
Punching machine cuts steel tapes in different razor shapes with different mould.
Coil machine is used to wrap razor strip up onto the steel wire and wind up the finished products into rolls.
Application: Razor barbed wire is extensively used for security isolation of military facilities, communication stations,power distribution stations, border prisons, landfill, community protection, schools, factories, farms, etc.
|
|
Punching machine |
Coiling machine |
|
Speed |
220-280m/h |
800 kgs/ 8hours |
|
Thickness |
0.5±0.05mm |
2.5mm |
|
Motor |
2.2 kw |
1.5kw |
|
Voltage |
Customized as request |
Customized as request |
|
Weight |
2200kgs |
300kgs |
|
Dimension |
1100*1000*2000mm |
1100*750*1200 |
|
Raw material |
Hot dipped galvanized steel sheet; Stainless steel sheet |
Hot dipped galvanized wire |
BLADE TYPES:
| STYLE | BARBE LENGTH | BARB WIDTH | BARB SPACE | STEEL TAPE SHAPE |
| BTO-10 | 10±1 mm | 13±1mm | 26±1mm |  |
| BTO-12-1 | 12±1mm | 13±1mm | 26±1mm |  |
| BTO-12-2 | 12±1mm | 15±1mm | 26±1mm |  |
| BTO-18 | 18±1mm | 15±1mm | 33±1mm |  |
| BT0-22 | 22±1mm | 15±1mm | 48±1mm |  |
| BTO-28 | 28±1mm | 15±1mm | 49±1mm |  |
| BTO-30 | 30±1mm | 18±1mm | 49±1mm |  |
| BTO-60 | 60±1mm | 32±1mm | 96±1mm |  |
| BTO-65 | 65±1mm | 21±1mm | 100±1mm |  |
