China Pole Piece Electrode Cutting Machine Pneumatic For Pouch Battery for sale
China Pole Piece Electrode Cutting Machine Pneumatic For Pouch Battery for sale
China Pole Piece Electrode Cutting Machine Pneumatic For Pouch Battery for sale

Pole Piece Electrode Cutting Machine Pneumatic For Pouch Battery

Price Negotiable
Price: USD2000-2400/Piece
MOQ: 1 Piece
Delivery Time: 14
Brand: ZHIK
Product Description

  • Pneumatic Pole Piece Electrode Die Cutting Machine For Pouch Battery

  • Pneumatic Pole Piece Electrode Die Cutting Machine





ZK-MQ180S is suitable for die-cutting and forming of battery positive and negative plates. The single-piece die-cutting of the plate-type pole piece is pneumatically used, and it can be placed in a glove box for use.





Product Name
Pneumatic pole piece die cutting machine
Model No.
ZK-MQ180S
Punching size
L85mmxW65mm (can be customized according to customer requirements)
Punching accuracy
±0.1 mm
Pressure
Max. 1T (0.5MPa compressed air), the recommended pressure for punching battery pole pieces is 500Kg
Die cutting stroke
35mm
Compressed air
0.5MPa compressed air, if put in the glove box, the gas used is the same as the glove box
Dimensions
L350mm*W230mm*H300mm
Equipment weight
32kg
