Lithium Iron Forklift Battery 48v450ah Lifepo4
Lithium Iron Forklift Lithium Battery 48v450ah Lifepo4 Lithium Battery Pack
Forklift 48V450Ah Lithium Battery EK-CP-0775
Technical Parameters
| NO. | Item | Specification | Remark |
| 1 | Size | 970mm*664mm*470mm | / |
| 2 | Combination mode | 3P15S | / |
| 3 | Rated capacity | 450Ah | 25±2℃,1.0C |
| 4 | Nominal voltage | 48V | / |
| 5 | High resistance | ≧50MΩ(DC500V) | 25±2℃ |
| 6 | Weight | ≈710kg | / |
| 7 | Total power of module | 21.6kwh | / |
| 8 | Maximum charging voltage | 48V | / |
| 9 | Maximum continuous charging current | 1C | 25±5℃ |
| 10 | Discharge cut-off voltage | 40.5V | / |
| 11 | Maximum continuous discharge current | 1C | 25±5℃ |
| 12 | Standard cycle life | ≥3000 times 80%Capacity retention | 1C/1C 25℃ |
Product Description
1. This product is made of YJT40110413-150Ah lithium iron phosphate battery in series and parallel. It is the standard module of EIKTO 15 core three-layer lithium iron phosphate battery.
2. Laser welding is performed between batteries using iron connectors.
3. The iron material is used as the shell to stabilize the module, which has high structural strength.
4. The module can be equipped with a battery heating system to make the battery work normally in a low temperature environment.
5. The internal structure of the module is made of refractory materials, which greatly reduces the risk caused by heating.
6. The module has the advantages of light weight, strong stability, high safety and long cycle life.
Product Advantages
1. Reliable structure: high anti vibration structure strength;
2. Controllable process: no over welding and faulty welding, ensuring 100% battery damage;
3. Safety design: adopt high safety lithium iron phosphate material system;
4. Good module stability: strict cell matching conditions, good cell consistency;
5. Green and environmental protection, no matter in production, use or scrap, does not contain or produce any toxic and harmful heavy metal elements and substances such as lead, mercury and cadmium.
Samples Show
Application
The products are widely used in industrial vehicles, engineering vehicles and other fields.
Packaging & Delivery
1. Guaranteed delivery time.
2. Well-trained and disciplined packing team.
3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
4. Sophisticated and professional logistic agent.
Competitive Advantages
1. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia and many other countries.
2. Flexible and Untraceable payment terms.
3. Good after-sale service.
4. We offer high quality products at competitive price in quick delivery.
