3.5 Ton Excavator 180 Degree Hydraulic Quick Hitch Q345B Excavator Quick Hitch Coupler
Excavator Title Quick Hitch Supplier from China 180 Quick Hitch for Sale
180 Degree Tilting Excavator Quick Hitch Description
180 degree tilting quick hitch is one of the excavator attachments that always be your right chico for the right job. When connecting different attachments gets challenging or turning attachments to a different degree cannot be achieved– the tilting quick coupler can provide your excavator with maximum versatility.
180° Side-to-Side Rotation Quick Hitch Specification
The tilting cylinder can improve the performance of the excavator's quick hitch so that the quick hitch can achieve more work in the shortest time. A quick coupler equipped with a tilting cylinder would achieve attachments versatility and durability.
| Model | Unit | CTHB00 | CTHB01 | CTHB02A | CTHB02B | CTHB04A | CTHB04B | CTHB06 | CTHB06B | CTHB08 |
| Rotation | Degree | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 |
| Torque | NM | 930 | 2870 | 4400 | 7190 | 4400 | 7190 | 10623 | 14500 | 18600 |
| Titling Cylinder Working Pressure | bar | 210 | 210 | 210 | 210 | 210 | 210 | 210 | 210 | 210 |
| Tilting Cylinder Required Flow | Lpm | 2-4 | 5-16 | 5-16 | 5-16 | 5-16 | 15-44 | 19-58 | 22-67 | 35-105 |
| Quick Couper Cylinder Working Pressure | bar | 25-300 | 25-300 | 25-300 | 25-300 | 25-300 | 25-300 | 25-300 | 25-300 | 25-300 |
| Quick Couper Cylinder Required Flow | Lpm | 15-25 | 15-25 | 15-25 | 15-25 | 15-25 | 15-25 | 15-25 | 17-29 | 20-25 |
| Suitable Excavator | ton | 0.8-1.5 | 2-3.5 | 4-6 | 4-6 | 7-9 | 7-9 | 10-15 | 16-20 | 20-25 |
| Overall Dimension | L*W*H (mm) | 477*280*567 | 477*280*567 | 518*310*585 | 545*310*585 | 541*350*608 | 582*350*649 | 720*450*784 | 800*530*864 | 858*500*911 |
| Total Weight (not include package) | kg | 55 | 112 | 156 | 156 | 170 | 208 | 413 | 445 | 655 |
* The Parameter above may change with the technology improvement, will not notice additionally, please understand.
YAKAI 180 Degree Quick Hitch Features Compared to Universal Quick Hitch
- 180° Side-to-Side Tilting: 90 degrees to one side, 90 degrees to another side
- Compact Design: Highly reduce the probability of losing in breakout force
- High-Quality Core Components: Core components are made of high-strength and anti-wear steel with experienced heat treatment technical to increase the service life.
- High tolerance for the dirt and dust
- Work Simultaneously: Bottom quick hitch detaches and top rotating part can work simultaneously.
- Service: Come with the following parts and are well packaged, easy to assemble, and deliver safely.
- Offer OEM/ ODM support, if Mass production without extra cost.
