24Ah Lifepo4 Lithium Ion Battery Replacement 12.8V For UPS Solar Electric Vehicles Electric Wheelchairs
LifePO4 SLA Replacement 12.8V24Ah Lifepo4 Battery For UPS/Solar/Electric Vehicles/Electric Wheelchairs
Product Description:
1. Deep discharge allowed up to 100%
2. BMS Protection,Very low self-discharge(<2% per month)
3. Excellent temperature robustness (-20 °C up to +60°C)
4. Constant power during discharge( very low internal resistance)
5. Very low Peukert's losses( energy efficiency>96%)
Product Usage:
Electric Bicycles/Scooters, Solar House Power, Automotive, Electric Bicycles/Scooters, Electric Folklifts/ vehicles/ Wheelchairs, BOATS,Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies,Golf Carts, Consumer Electronics
Parameters:
| Function Parameter | |
| Norminal Capacity | 24Ah |
| Norminal Voltage | 12V (Customized 3.2V 12V 24V 36V 48V) |
| Internal Resistance | ≤22mΩ |
| Cycle Life | >5000 |
| Months Self Discharge | <3% |
| Charge Data | |
| DC Normal Charge Voltage | 14.6V |
| Dimension | 165*125*175mm Or Customized |
| Allowed Max. Charge Current | 50Adc |
| 14.6V | |
| Discharge Data | |
| Continuous Discharge Current | 100A |
| Allowed Max. discharge current | 100A (option:100Adc) |
| Working Condition | |
| Charge Temperature | 0℃ to 45℃ (32℉ to 113℉) @60±25% Relative Humidity |
| Discharge Temperature | -20℃ to 60℃ (-4℉ to 140℉) @60±25% Relative Humidity |
| Storage Temperature | 0℃ to 40℃ (32℉ to 104℉) @60±25% Relative Humidity |
| Enclosure Protection Level | IP20 |
