8.8mm Antistatic Edge Corrugated Machine Spare Parts Double Facer Belts
Corrugated Machine Spare Parts 8.8mm Antistatic Edge Reinforcemen Double Facer Belt
Performance Index:
| MODEL |
EDGE REINFORCEMEN FCH-FZ |
| NEIGHT KG/M2 | 7.3 |
| THICKNESS mm | 8.8±0.3 |
| WIDTH mm | 1400-3300 |
| THERMAL ENDURANCE℃ | 180℃ |
| FRICTION FACTOR | 0.45 |
| BREAKING STRENGTH KG/M | 30000 |
| MOISTURE ABSORPTION /RELEASE RATIO | 129% |
| STEAM LM2-H | 6.560 |
| FLEXIBILITY TRANSVERSE | 0.77%/180℃ |
| FLEXIBILITY LONGITUDINAL | 0.9%/180℃ |
Weaving technic: multi-layer single filing
Material: polyester yarn, polyester filament, Tencel and Kevlar
Feature: weaving texture clear, neat edge, stable dimension, heat and pressure-resisting , anti-static, outstanding traction, surface and seam-sealing even.
Great absorbency, drying and anti- static enable corrugated board transport flawlessly and efficiently in production line
Lifetime: 80 million meter service length in laboratory test condition
1, The first domestic machine capable of producing a conveyor belt with a large width of 3300 mm
3, The unique Company participating in the domestic industry standard customization of conveyor belts
